Chaos Testing KubeDB ClickHouse with Chaos Mesh

Prerequisites and Cluster Setup

Prerequisites:

A running Kubernetes cluster.
KubeDB installed in the cluster.
kubectl configured for that cluster.
Chaos Mesh installed with the correct container runtime socket.
A disposable demo namespace. These tests can disrupt service and delete data.

For K3s, Chaos Mesh must use /run/k3s/containerd/containerd.sock:

➤ helm upgrade --install chaos-mesh chaos-mesh/chaos-mesh \
        --namespace chaos-mesh \
        --create-namespace \
        --version 2.8.4 \
        --set dashboard.create=true \
        --set dashboard.securityMode=false \
        --set dnsServer.create=true \
        --set chaosDaemon.runtime=containerd \
        --set chaosDaemon.socketPath=/run/k3s/containerd/containerd.sock \
        --set chaosDaemon.privileged=true
Release "chaos-mesh" does not exist. Installing it now.
NAME: chaos-mesh
LAST DEPLOYED: Tue Sep  8 10:13:50 2026
NAMESPACE: chaos-mesh
STATUS: deployed
REVISION: 1
DESCRIPTION: Install complete

For other Kubernetes distributions, configure the runtime and socket path for the installed container runtime.

Create the disposable namespace:

kubectl create ns demo

Create the local manifest directories:

mkdir -p clickhouse-chaos-testing/setup
mkdir -p clickhouse-chaos-testing/tests
cd clickhouse-chaos-testing

Confirm that the required ClickHouse version and storage class are available:

➤ kubectl get clickhouseversion 26.2.6
NAME     VERSION   DB_IMAGE                                        DEPRECATED   AGE
26.2.6   26.2.6    docker.io/clickhouse/clickhouse-server:26.2.6                27d

➤ kubectl get storageclass local-path
NAME                   PROVISIONER             RECLAIMPOLICY   VOLUMEBINDINGMODE      ALLOWVOLUMEEXPANSION   AGE
local-path (default)   rancher.io/local-path   Delete          WaitForFirstConsumer   true                   27d

Verify KubeDB and Chaos Mesh Installation

➤ kubectl get pods -n kubedb
NAME                                            READY   STATUS             RESTARTS         AGE
kubedb-kubedb-autoscaler-0                      1/1     Running            3 (2d9h ago)     21d
kubedb-kubedb-ops-manager-0                     1/1     Running            1 (2d9h ago)     7d22h
kubedb-kubedb-provisioner-0                     1/1     Running            1 (2d9h ago)     5d13h
kubedb-kubedb-webhook-server-65949766c4-xlfpz   1/1     Running            1 (2d9h ago)     12d
kubedb-petset-85c9d79865-lfqww                  1/1     Running            3 (2d9h ago)     21d
kubedb-sidekick-86f897c579-djk65                1/1     Running            3 (2d9h ago)     21d

➤ kubectl get pods -n chaos-mesh

NAME                                        READY   STATUS    RESTARTS   AGE
chaos-controller-manager-7d44d6dd54-7chxr   1/1     Running   0          3m50s
chaos-controller-manager-7d44d6dd54-fd5cv   1/1     Running   0          3m50s
chaos-controller-manager-7d44d6dd54-prstq   1/1     Running   0          3m50s
chaos-daemon-dkfxd                          1/1     Running   0          3m50s
chaos-dashboard-5db97f969f-gwm96            1/1     Running   0          3m50s
chaos-dns-server-6d8fd4b8b5-kjwg7           1/1     Running   0          3m50s

➤ kubectl get crd \
        podchaos.chaos-mesh.org \
        networkchaos.chaos-mesh.org \
        stresschaos.chaos-mesh.org \
        iochaos.chaos-mesh.org \
        dnschaos.chaos-mesh.org \
        timechaos.chaos-mesh.org
NAME                          CREATED AT
podchaos.chaos-mesh.org       2026-08-28T07:50:32Z
networkchaos.chaos-mesh.org   2026-08-28T07:50:32Z
stresschaos.chaos-mesh.org    2026-08-28T07:50:32Z
iochaos.chaos-mesh.org        2026-08-28T07:50:32Z
dnschaos.chaos-mesh.org       2026-08-28T07:50:32Z
timechaos.chaos-mesh.org      2026-08-28T07:50:33Z

All operator and Chaos Mesh pods must be Ready before continuing.

Test Scope

This walkthrough injects controlled failures into a KubeDB-managed ClickHouse cluster and verifies client availability, acknowledged-data safety, replica convergence, Keeper health, and complete fault removal.

Test Procedure

The walkthrough performs the following procedure:

Deploy a highly available KubeDB-managed ClickHouse cluster.
Run a continuous workload that inserts rows with unique IDs.
Compare the expected behavior with the behavior actually observed.
Verify recovery by running database queries and checking replica consistency, Keeper health, pod state, and storage state.

The experiments were executed against a fresh KubeDB-managed ClickHouse 26.2.6 cluster with two shards, two replicas per shard, and three dedicated ClickHouse Keeper members.

The recoverable database faults preserved the acknowledged ClickHouse data. TimeChaos did not demonstrate a live clock skew: it stopped the target process and required manual SIGCONT after cleanup, so experiment 22 is reported as a chaos-tool limitation rather than a pass. At the recovery checkpoints, both replicas of each shard had identical row counts and payload checksums, replication queues were empty, and Keeper had exactly one leader and two followers.

Create a ClickHouse Cluster

The test topology deliberately separates two different kinds of redundancy:

Two replicas protect each data shard.
Three Keeper members provide a coordination quorum.

Create `setup/clickhouse-chaos.yaml`

Save the following manifest as setup/clickhouse-chaos.yaml:

apiVersion: kubedb.com/v1alpha2
kind: ClickHouse
metadata:
  name: clickhouse-chaos
  namespace: demo
  labels:
    chaos-test.kubedb.com/suite: clickhouse-chaos
spec:
  version: 26.2.6
  clusterTopology:
    cluster:
      name: chaos-cluster
      shards: 2
      replicas: 2
      storageType: Durable
      storage:
        storageClassName: local-path
        accessModes:
          - ReadWriteOnce
        resources:
          requests:
            storage: 4Gi
      podTemplate:
        spec:
          containers:
            - name: clickhouse
              resources:
                requests:
                  cpu: 250m
                  memory: 1Gi
                limits:
                  cpu: "1"
                  memory: 4Gi
    clickHouseKeeper:
      externallyManaged: false
      spec:
        replicas: 3
        storageType: Durable
        storage:
          storageClassName: local-path
          accessModes:
            - ReadWriteOnce
          resources:
            requests:
              storage: 1Gi
        podTemplate:
          spec:
            containers:
              - name: clickhouse-keeper
                resources:
                  requests:
                    cpu: 100m
                    memory: 256Mi
                  limits:
                    cpu: 500m
                    memory: 512Mi
  deletionPolicy: WipeOut

Create the cluster and wait for the database:

➤ kubectl apply -f setup/clickhouse-chaos.yaml
clickhouse.kubedb.com/clickhouse-chaos created

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=15m
clickhouse.kubedb.com/clickhouse-chaos condition met

➤ kubectl get clickhouse,petset,pods,pvc -n demo
NAME                                     VERSION   STATUS   AGE
clickhouse.kubedb.com/clickhouse-chaos   26.2.6    Ready    2m21s

NAME                                                                  AGE
petset.apps.k8s.appscode.com/clickhouse-chaos-chaos-cluster-shard-0   2m16s
petset.apps.k8s.appscode.com/clickhouse-chaos-chaos-cluster-shard-1   2m13s
petset.apps.k8s.appscode.com/clickhouse-chaos-keeper                  2m18s

NAME                                           READY   STATUS    RESTARTS   AGE
pod/clickhouse-chaos-chaos-cluster-shard-0-0   1/1     Running   0          2m15s
pod/clickhouse-chaos-chaos-cluster-shard-0-1   1/1     Running   0          2m9s
pod/clickhouse-chaos-chaos-cluster-shard-1-0   1/1     Running   0          2m13s
pod/clickhouse-chaos-chaos-cluster-shard-1-1   1/1     Running   0          2m8s
pod/clickhouse-chaos-keeper-0                  1/1     Running   0          2m17s
pod/clickhouse-chaos-keeper-1                  1/1     Running   0          2m11s
pod/clickhouse-chaos-keeper-2                  1/1     Running   0          2m6s

NAME                                                                  STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   VOLUMEATTRIBUTESCLASS   AGE
persistentvolumeclaim/data-clickhouse-chaos-chaos-cluster-shard-0-0   Bound    pvc-9773c0e0-8bd6-4a67-b445-444255b61074   4Gi        RWO            local-path     <unset>                 2m15s
persistentvolumeclaim/data-clickhouse-chaos-chaos-cluster-shard-0-1   Bound    pvc-af84e532-ec8b-4ddc-938f-34d6a21bdeeb   4Gi        RWO            local-path     <unset>                 2m9s
persistentvolumeclaim/data-clickhouse-chaos-chaos-cluster-shard-1-0   Bound    pvc-eecf7db8-b9b5-4888-b1aa-71e70ea65119   4Gi        RWO            local-path     <unset>                 2m13s
persistentvolumeclaim/data-clickhouse-chaos-chaos-cluster-shard-1-1   Bound    pvc-35ef4112-0c9d-42b1-973a-f26389b04864   4Gi        RWO            local-path     <unset>                 2m8s
persistentvolumeclaim/data-clickhouse-chaos-keeper-0                  Bound    pvc-531f098d-5196-490d-b6ba-b3584755b06c   1Gi        RWO            local-path     <unset>                 2m17s
persistentvolumeclaim/data-clickhouse-chaos-keeper-1                  Bound    pvc-41c5eecc-1f51-477d-aa7f-22e2e1c88ba9   1Gi        RWO            local-path     <unset>                 2m11s
persistentvolumeclaim/data-clickhouse-chaos-keeper-2                  Bound    pvc-e893bff9-8ba5-4da4-92f7-b0b125e4777f   1Gi        RWO            local-path     <unset>                 2m6s

KubeDB creates and references clickhouse-chaos-auth automatically:

➤ kubectl get secret -n demo clickhouse-chaos-auth
NAME                    TYPE                       DATA   AGE
clickhouse-chaos-auth   kubernetes.io/basic-auth   2      4m18s

Test Environment

Component	Value
Kubernetes	K3s v1.36.3+k3s1, single node
Namespace	`demo`
ClickHouse resource	`clickhouse-chaos`
ClickHouse version	`26.2.6`
Data topology	2 shards × 2 replicas
Coordination	3 ClickHouse Keeper members
Storage	4Gi `local-path` PVC per ClickHouse pod
ClickHouse limit	1 CPU, 4Gi memory
Keeper limit	500m CPU, 512 MiB memory
Chaos Mesh	2.8.4
Container runtime	K3s containerd
Chaos daemon socket	`/run/k3s/containerd/containerd.sock`

Chaos Testing

A continuous write client exposes availability failures and ambiguous writes that an idle database would not reveal.

Continuous ClickHouse Write Workload

ClickHouse exposes a SQL interface. The workload uses SQL to create tables, insert test data, count unique IDs, and inspect replication state.

The table used ReplicatedMergeTree, while clients wrote through a Distributed table across chaos-cluster. Each batch inserted 100 rows with server-generated UUIDs and insert_distributed_sync=1.

A UUID is a randomly generated unique identifier assigned to each row. Comparing the total row count with the unique-ID count detects accidental duplicates.

Create the schema from one data pod. The operator already injects CLICKHOUSE_USER and CLICKHOUSE_PASSWORD into the ClickHouse container, so no credential needs to be copied into the command:

kubectl exec -i -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  bash -c '
    clickhouse-client \
      --user "$CLICKHOUSE_USER" \
      --password "$CLICKHOUSE_PASSWORD" \
      --multiquery
  ' <<'SQL'
CREATE DATABASE IF NOT EXISTS chaos_v2 ON CLUSTER `chaos-cluster`;

CREATE TABLE IF NOT EXISTS chaos_v2.events_local
ON CLUSTER `chaos-cluster`
(
  id UUID,
  inserted_at DateTime64(3),
  payload UInt64
)
ENGINE = ReplicatedMergeTree(
  '/clickhouse/{installation}/{cluster}/tables/{shard}/{database}/{table}',
  '{replica}'
)
ORDER BY id;

CREATE TABLE IF NOT EXISTS chaos_v2.events
ON CLUSTER `chaos-cluster`
AS chaos_v2.events_local
ENGINE = Distributed(
  'chaos-cluster',
  'chaos_v2',
  'events_local',
  cityHash64(id)
);
SQL

The command exited successfully; ClickHouse created the database and both tables on the cluster.

Create `setup/clickhouse-workload.yaml`

The workload client inserts 100 rows, waits for synchronous Distributed delivery, records whether the batch was acknowledged, then repeats.

Save the following manifest as setup/clickhouse-workload.yaml:

The while true loop runs inside the workload container. Kubernetes starts the script once, and it produces traffic until the workload is paused.

apiVersion: v1
kind: ConfigMap
metadata:
  name: clickhouse-chaos-workload
  namespace: demo
  labels:
    chaos-test.kubedb.com/suite: clickhouse-chaos
data:
  run.sh: |
    #!/usr/bin/env bash
    set -u
    mkdir -p /state
    test -f /state/attempt_batches || printf '0\n' > /state/attempt_batches
    test -f /state/success_batches || printf '0\n' > /state/success_batches
    test -f /state/failed_batches || printf '0\n' > /state/failed_batches

    while true; do
      if test -f /state/pause; then
        sleep 1
        continue
      fi

      attempt=$(( $(cat /state/attempt_batches) + 1 ))
      printf '%s\n' "$attempt" > /state/attempt_batches

      if timeout --signal=TERM --kill-after=5s 20s clickhouse-client \
        --host clickhouse-chaos.demo.svc \
        --user "$CH_USER" \
        --password "$CH_PASSWORD" \
        --connect_timeout 5 \
        --send_timeout 10 \
        --receive_timeout 10 \
        --query "INSERT INTO chaos_v2.events
          SELECT generateUUIDv4(), now64(3), rand64()
          FROM numbers(100)
          SETTINGS insert_distributed_sync=1"; then
        value=$(( $(cat /state/success_batches) + 1 ))
        printf '%s\n' "$value" > /state/success_batches
        printf '%s success attempt=%s rows=100\n' \
          "$(date -Iseconds)" "$attempt"
      else
        value=$(( $(cat /state/failed_batches) + 1 ))
        printf '%s\n' "$value" > /state/failed_batches
        printf '%s failure attempt=%s\n' \
          "$(date -Iseconds)" "$attempt" >&2
      fi
      sleep 1
    done
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: clickhouse-chaos-workload
  namespace: demo
  labels:
    chaos-test.kubedb.com/suite: clickhouse-chaos
spec:
  replicas: 1
  selector:
    matchLabels:
      app: clickhouse-chaos-workload
  template:
    metadata:
      labels:
        app: clickhouse-chaos-workload
        chaos-test.kubedb.com/suite: clickhouse-chaos
    spec:
      containers:
        - name: workload
          image: docker.io/clickhouse/clickhouse-server:26.2.6
          command:
            - /bin/bash
            - /scripts/run.sh
          env:
            - name: CH_USER
              valueFrom:
                secretKeyRef:
                  name: clickhouse-chaos-auth
                  key: username
            - name: CH_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: clickhouse-chaos-auth
                  key: password
          resources:
            requests:
              cpu: 50m
              memory: 64Mi
            limits:
              cpu: 250m
              memory: 256Mi
          volumeMounts:
            - name: script
              mountPath: /scripts
              readOnly: true
            - name: state
              mountPath: /state
      volumes:
        - name: script
          configMap:
            name: clickhouse-chaos-workload
            defaultMode: 365
        - name: state
          emptyDir: {}

Start the client and wait for at least ten successful batches:

➤ kubectl apply -f setup/clickhouse-workload.yaml
configmap/clickhouse-chaos-workload configured
deployment.apps/clickhouse-chaos-workload created

➤ kubectl rollout status -n demo \
        deployment/clickhouse-chaos-workload --timeout=3m
deployment "clickhouse-chaos-workload" successfully rolled out

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
    -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Kubernetes generates the suffix in this pod name. Subsequent commands use the workload pod name returned for the current cluster.

$ kubectl logs -n demo -f clickhouse-chaos-workload-64d7d5c85f-fqjdp
2026-09-08T04:44:40+00:00 success attempt=1 rows=100
2026-09-08T04:44:41+00:00 success attempt=2 rows=100
2026-09-08T04:44:43+00:00 success attempt=3 rows=100
2026-09-08T04:44:44+00:00 success attempt=4 rows=100
2026-09-08T04:44:45+00:00 success attempt=5 rows=100
2026-09-08T04:44:46+00:00 success attempt=6 rows=100
2026-09-08T04:44:47+00:00 success attempt=7 rows=100
2026-09-08T04:44:48+00:00 success attempt=8 rows=100
2026-09-08T04:44:49+00:00 success attempt=9 rows=100
2026-09-08T04:44:51+00:00 success attempt=10 rows=100

When the log shows at least ten success lines, press Ctrl-C. This stops only log streaming; the workload Deployment continues writing in the cluster.

The client marked a batch as acknowledged only when ClickHouse returned a success response. If the client timed out, the outcome was ambiguous. For example, ClickHouse could accept the rows but the response could arrive after the client stopped waiting. Those rows remain in the database even though the client recorded the attempt as failed. Therefore, acknowledged batches × 100 is the minimum number of rows known to have been accepted, not necessarily the final row count.

Before the first test, the client had 35 successful batches, zero failures, and 3,500 unique rows. At the end it had:

attempted batches:     1,342
acknowledged batches:  1,208
failed/ambiguous:      134
acknowledged rows:     120,800
actual rows:           122,695
unique IDs:            122,695

The client attempted 1,342 batches. It received success for 1,208 batches, so 1,208 × 100 = 120,800 rows were definitely acknowledged. Another 134 attempts timed out or returned an error. Some rows from those attempts had already reached ClickHouse. Together they account for the additional 1,895 rows. Since all 122,695 IDs were unique, these additional rows were neither duplicate rows nor evidence of corruption.

Mandatory Recovery Gate

After each Chaos Mesh experiment, delete the Chaos Mesh object, pause writes, and require all of the following before continuing:

Pause the workload and confirm its active client stopped.
Require the ClickHouse resource and all four ClickHouse plus three Keeper pods to be Ready.
Confirm that no test Chaos Mesh object remains.
Perform an authenticated probe insert and require count() == uniqExact(id) on the Distributed table.
Require matching local counts and checksums for each shard in two consecutive checks. A check is a set of query results collected at one moment, not a volume snapshot or backup. Repeating it avoids judging a brief part-visibility delay immediately after Keeper returns.
Require system.replicas to show writable replicas, queue size zero, two total replicas, and two active replicas.
Require all three Keepers to answer mntr, with one leader and two followers.
Require running ClickHouse processes and normal data mounts, with no stale toda FUSE layer.

Pause the workload and allow the active client invocation to finish:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
    -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- touch /state/pause

The command prints nothing.

$ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- bash -c   'if pgrep -x clickhouse-client >/dev/null; then echo "client still active"; else echo "workload paused"; fi'
workload paused

Require ClickHouse and all seven database pods to be healthy:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=10m
clickhouse.kubedb.com/clickhouse-chaos condition met

➤ kubectl get clickhouse,petset,pods -n demo
NAME                                     VERSION   STATUS   AGE
clickhouse.kubedb.com/clickhouse-chaos   26.2.6    Ready    28m

NAME                                                                  AGE
petset.apps.k8s.appscode.com/clickhouse-chaos-chaos-cluster-shard-0   28m
petset.apps.k8s.appscode.com/clickhouse-chaos-chaos-cluster-shard-1   28m
petset.apps.k8s.appscode.com/clickhouse-chaos-keeper                  28m

NAME                                             READY   STATUS    RESTARTS   AGE
pod/clickhouse-chaos-chaos-cluster-shard-0-0     1/1     Running   0          28m
pod/clickhouse-chaos-chaos-cluster-shard-0-1     1/1     Running   0          28m
pod/clickhouse-chaos-chaos-cluster-shard-1-0     1/1     Running   0          28m
pod/clickhouse-chaos-chaos-cluster-shard-1-1     1/1     Running   0          28m
pod/clickhouse-chaos-keeper-0                    1/1     Running   0          28m
pod/clickhouse-chaos-keeper-1                    1/1     Running   0          28m
pod/clickhouse-chaos-keeper-2                    1/1     Running   0          28m
pod/clickhouse-chaos-workload-64d7d5c85f-fqjdp   1/1     Running   0          6m39s

Confirm that no test fault remains:

➤ kubectl get podchaos,networkchaos,stresschaos,iochaos,dnschaos,timechaos -n demo
No resources found in demo namespace.

Check the Distributed table. The first two values must match, and the count must be at least successful_batches × 100:

kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- bash -c '
  clickhouse-client \
    --host clickhouse-chaos.demo.svc \
    --user "$CH_USER" \
    --password "$CH_PASSWORD" \
    --query "INSERT INTO chaos_v2.events
      SELECT generateUUIDv4(), now64(3), rand64()
      SETTINGS insert_distributed_sync=1"
'

$ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- bash -c '
  clickhouse-client \
    --host clickhouse-chaos.demo.svc \
    --user "$CH_USER" \
    --password "$CH_PASSWORD" \
    --query "SELECT count(), uniqExact(id), sum(payload)
             FROM chaos_v2.events FORMAT TSV"
'
4201	4201	18251318426044052401

Check every local replica. Run each command separately:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events_local FORMAT TSV"'
2100	2100	15819459328062010837

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events_local FORMAT TSV"'
2100	2100	15819459328062010837

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events_local FORMAT TSV"'
2101	2101	2431859097982041564

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events_local FORMAT TSV"'
2101	2101	2431859097982041564

Shard-0’s two lines match, and shard-1’s two lines match. Run the same four commands again. The second check must return the same four lines before continuing.

Check system.replicas on each pod, one at a time. The six values are is_readonly, queue_size, total_replicas, active_replicas, lost_part_count, and absolute_delay:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --database chaos_v2 \
  --query "SELECT is_readonly, queue_size, total_replicas, active_replicas,
                  lost_part_count, absolute_delay
           FROM system.replicas WHERE database=currentDatabase() FORMAT TSV"'
0	0	2	2	0	0

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --database chaos_v2 \
  --query "SELECT is_readonly, queue_size, total_replicas, active_replicas,
                  lost_part_count, absolute_delay
           FROM system.replicas WHERE database=currentDatabase() FORMAT TSV"'
0	0	2	2	0	0

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --database chaos_v2 \
  --query "SELECT is_readonly, queue_size, total_replicas, active_replicas,
                  lost_part_count, absolute_delay
           FROM system.replicas WHERE database=currentDatabase() FORMAT TSV"'
0	0	2	2	0	0

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --database chaos_v2 \
  --query "SELECT is_readonly, queue_size, total_replicas, active_replicas,
                  lost_part_count, absolute_delay
           FROM system.replicas WHERE database=currentDatabase() FORMAT TSV"'
0	0	2	2	0	0

The values mean writable, empty queue, two configured replicas, two active replicas, no lost parts, and no replication delay.

Check Keeper directly rather than inferring quorum from ClickHouse status. Run each command separately:

➤ kubectl exec -n demo clickhouse-chaos-keeper-0 \
  -c clickhouse-keeper -- bash -c '
exec 3<>/dev/tcp/127.0.0.1/9181
printf "mntr\n" >&3
timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

➤ kubectl exec -n demo clickhouse-chaos-keeper-1 \
  -c clickhouse-keeper -- bash -c '
exec 3<>/dev/tcp/127.0.0.1/9181
printf "mntr\n" >&3
timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

➤ kubectl exec -n demo clickhouse-chaos-keeper-2 \
  -c clickhouse-keeper -- bash -c '
exec 3<>/dev/tcp/127.0.0.1/9181
printf "mntr\n" >&3
timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
leader

The leader can change, but the result must contain exactly one leader and two followers. Finally, verify each ClickHouse PID 1 one at a time:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 \
  -c clickhouse -- ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 \
  -c clickhouse -- ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 \
  -c clickhouse -- ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 \
  -c clickhouse -- ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

Check each data mount separately:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 \
  -c clickhouse -- mount | grep /var/lib/clickhouse
/dev/vda1 on /var/lib/clickhouse type ext4 (rw,relatime,discard,errors=remount-ro,commit=30)

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 \
  -c clickhouse -- mount | grep /var/lib/clickhouse
/dev/vda1 on /var/lib/clickhouse type ext4 (rw,relatime,discard,errors=remount-ro,commit=30)

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 \
  -c clickhouse -- mount | grep /var/lib/clickhouse
/dev/vda1 on /var/lib/clickhouse type ext4 (rw,relatime,discard,errors=remount-ro,commit=30)

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 \
  -c clickhouse -- mount | grep /var/lib/clickhouse
/dev/vda1 on /var/lib/clickhouse type ext4 (rw,relatime,discard,errors=remount-ro,commit=30)

PID 1 must not contain state T, and data must be on the normal filesystem, not a toda FUSE mount. These checks matter because Ready alone cannot prove Keeper availability, replica equality, or complete Chaos Mesh cleanup.

Running Each Chaos Experiment

For each test that uses a Chaos Mesh manifest, start with the following safe sequence. The experiment sections add their fault-specific impact and recovery checks. Experiment 25 instead gives its direct pod-and-PVC deletion procedure.

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Start the workload using the pod name returned above:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- rm -f /state/pause

The command prints nothing on success. Validate the manifest against the API server:

➤ kubectl apply --dry-run=server -f tests/01-pod-kill.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-01 created (server dry run)

Inject the fault:

➤ kubectl apply -f tests/01-pod-kill.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-01 created

Prove that Chaos Mesh injected it:

➤ kubectl wait -n demo --for=condition=AllInjected \
  -f tests/01-pod-kill.yaml --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-01 condition met

Observe ClickHouse during the fault:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    7m

Read the workload counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- bash -c '
  printf "attempts="; cat /state/attempt_batches
  printf "success="; cat /state/success_batches
  printf "failed="; cat /state/failed_batches
'
attempts=46
success=46
failed=0

Remove the experiment:

➤ kubectl delete -f tests/01-pod-kill.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-01" deleted from demo namespace

Deletion only removes the injected fault; it does not prove that ClickHouse recovered. After deletion, run every command in the Mandatory Recovery Gate section immediately above. “Run the full gate” means:

Pause the workload and confirm its active client has stopped.
Wait for ClickHouse to become Ready and check all seven database pods.
Confirm that no Chaos Mesh resource from the test remains.
Perform the one-row probe insert and query the Distributed table.
Check every local replica in two stable snapshots.
Check system.replicas on all four data pods.
Check all three Keeper roles.
Check PID 1 and the data mount on all four ClickHouse pods.

All eight checks must pass before unpausing the workload for the next experiment.

The commands above use test 1 as the example. For each subsequent experiment, replace tests/01-pod-kill.yaml with the filename printed at the start of that experiment. Run the commands in order, and start the next fault only after the mandatory recovery gate passes.

For a timed experiment, wait for its duration to expire before deletion. For example, test 2 uses:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  -f tests/02-pod-failure.yaml --timeout=150s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-02 condition met

➤ kubectl delete -f tests/02-pod-failure.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-02" deleted from demo namespace

For one-shot pod-kill and container-kill tests, delete the Chaos object after AllInjected and after proving the replacement pod or container is healthy; those tests do not have a duration to wait for.

The AllInjected check is required. An initial DNS test used a pattern that did not match the full name queried by the resolver. Treating manifest creation as proof of injection would have produced a false pass.

Pod and Keeper Chaos

Chaos#1: Kill One ClickHouse Replica

Create `tests/01-pod-kill.yaml`

Save this YAML as tests/01-pod-kill.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-01
  namespace: demo
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  gracePeriod: 0

What this chaos does: Abruptly deletes shard-0 replica-0 with no graceful shutdown.

Expected behavior: The sibling replica should keep the shard available, PetSet should create a replacement pod, and replication should catch it up. The target pod UID must change, but acknowledged data must not.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

Keep the workload running while observing the fault and recovery transition.

Record the target UID before applying the manifest, then confirm that it changes after injection.

Demonstrate impact and recovery

Confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    6m

Record the original pod UID:

➤ kubectl get pod -n demo \
        clickhouse-chaos-chaos-cluster-shard-0-0 \
        -o jsonpath='{.metadata.uid}{"\n"}'
e8970f8d-477f-42ba-87ed-edc6d0f41a89

Apply this experiment:

➤ kubectl apply -f tests/01-pod-kill.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-01 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        podchaos/clickhouse-chaos-exp-01 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-01 condition met

Observe the live impact:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    7m

Wait for PetSet to make the replacement pod ready:

➤ kubectl wait -n demo --for=condition=Ready \
        pod/clickhouse-chaos-chaos-cluster-shard-0-0 --timeout=5m
pod/clickhouse-chaos-chaos-cluster-shard-0-0 condition met

Confirm that the replacement has a new UID:

➤ kubectl get pod -n demo \
        clickhouse-chaos-chaos-cluster-shard-0-0 \
        -o jsonpath='{.metadata.uid}{"\n"}'
a1519479-69cf-45a5-b50a-550bcc5f941c

Delete the experiment:

➤ kubectl delete -f tests/01-pod-kill.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-01" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing. Record the stable workload counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
46 46 0

Verify the two shard-0 replicas separately:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
2319	2319	13499264341016960427

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- \
        bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
2319	2319	13499264341016960427

Observed behavior:

The target pod UID changed from e8970f8d-477f-42ba-87ed-edc6d0f41a89 to a1519479-69cf-45a5-b50a-550bcc5f941c. ClickHouse stayed Ready; the workload advanced from 18 18 0 to 46 46 0. After cleanup, the replica was writable with an empty queue and two active replicas.

Result: PASS — the sibling kept the shard available and the replacement converged automatically.

Chaos#2: Hold One Replica Failed

Create `tests/02-pod-failure.yaml`

Save this YAML as tests/02-pod-failure.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-02
  namespace: demo
spec:
  action: pod-failure
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-1

What this chaos does: Makes shard-0 replica-1 continuously unavailable for 45 seconds instead of allowing Kubernetes to replace it immediately.

Expected behavior: ClickHouse should report a degraded state while the sibling replica continues serving the shard. When the fault ends, the same pod should become reachable and converge without manual repair.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

Keep the workload running while observing the fault and recovery transition.

Before injecting the fault, the fresh cluster was healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    8m

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-0-1 \
  -o jsonpath='{.metadata.uid}{" "}{.status.containerStatuses[0].restartCount}{"\n"}'
61f18b79-43f9-44a8-b9bc-d1db5baf6b29 0

Apply the file and confirm that Chaos Mesh really injected the failure. A created object alone is not evidence that the fault reached the target:

➤ kubectl apply -f tests/02-pod-failure.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-02 created

➤ kubectl get podchaos -n demo clickhouse-chaos-exp-02 \
        -o jsonpath='{range .status.conditions[*]}{.type}={.status}{"\n"}{end}'
Selected=True
AllInjected=True
AllRecovered=False
Paused=False

While the 45-second fault was active, the target pod stayed present but its container restarted. ClickHouse status may be Critical at this sample but the healthy sibling could serve the shard:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS     AGE
clickhouse-chaos   26.2.6    Critical   9m

Prove that the selected replica rejects a direct SQL connection while the fault is active:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'clickhouse-client --host clickhouse-chaos-chaos-cluster-shard-0-1.clickhouse-chaos-pods.demo.svc --user "$CH_USER" --password "$CH_PASSWORD" --query "SELECT 1"; echo exit_code=$?'
Code: 210. DB::NetException: Connection refused
exit_code=210

➤ kubectl get pod -n demo \
        clickhouse-chaos-chaos-cluster-shard-0-1
NAME                                       READY   STATUS    RESTARTS      AGE
clickhouse-chaos-chaos-cluster-shard-0-1   1/1     Running   1              9m

After the duration elapsed, Chaos Mesh reported recovery.

➤ kubectl get podchaos -n demo clickhouse-chaos-exp-02 \
        -o jsonpath='{range .status.conditions[*]}{.type}={.status}{"\n"}{end}'
Selected=True
AllInjected=False
AllRecovered=True
Paused=False

➤ kubectl delete -f tests/02-pod-failure.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-02" deleted from demo namespace

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    10m

The UID is unchanged and the final restart count is two:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-0-1 \
  -o jsonpath='{.metadata.uid}{" "}{.status.containerStatuses[0].restartCount}{"\n"}'
61f18b79-43f9-44a8-b9bc-d1db5baf6b29 2

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
    --query "SELECT is_readonly, queue_size, total_replicas, active_replicas
             FROM system.replicas
             WHERE database='\''chaos_v2'\'' AND table='\''events_local'\''
  FORMAT TSV"'
0	0	2	2

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
107 99 8

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

The target kept the same UID, 61f18b79-43f9-44a8-b9bc-d1db5baf6b29, and restarted twice. A direct query returned Connection refused, ClickHouse became Critical, and the workload moved from 46 46 0 to 107 99 8. After AllRecovered=True, the test still waited for SQL and ClickHouse Ready.

Result: PASS — the sustained replica failure was visible and the replica healed without manual repair.

Chaos#3: Kill Only the ClickHouse Container

Create `tests/03-container-kill.yaml`

Save this YAML as tests/03-container-kill.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-03
  namespace: demo
spec:
  action: container-kill
  mode: one
  containerNames:
    - clickhouse
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-1-0

What this chaos does: Kills only the clickhouse process container while leaving the pod object and its PVC in place.

Expected behavior: Kubernetes should restart the container, ClickHouse should reconnect to Keeper and replication, and the restart count should increase without a pod UID change.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Compare the clickhouse container restart count before and after injection.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    11m

Record the pod UID and restart count before injection:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-1-0 \
        -o jsonpath='{.metadata.uid}{" "}{.status.containerStatuses[0].restartCount}{"\n"}'
326909c8-1fe4-4c3e-99f8-3c14f8680d4b 0

Apply this experiment:

➤ kubectl apply -f tests/03-container-kill.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-03 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        podchaos/clickhouse-chaos-exp-03 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-03 condition met

Observe the live impact:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-1-0 \
        -o jsonpath='{.metadata.uid}{"\n"}{.status.containerStatuses[0].restartCount}{"\n"}'
326909c8-1fe4-4c3e-99f8-3c14f8680d4b
1

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    12m

Delete the experiment:

➤ kubectl delete -f tests/03-container-kill.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-03" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
134 126 8

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

The pod UID remained 326909c8-1fe4-4c3e-99f8-3c14f8680d4b, while its restart count changed from 0 to 1. ClickHouse stayed Ready; the workload moved from 107 99 8 to 134 126 8.

Result: PASS — Kubernetes restarted only the ClickHouse container and it rejoined replication.

Chaos#4: Repeat Alternating Pod Kills

Create `tests/04-a-pod-kill.yaml`

Save the first fault as tests/04-a-pod-kill.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-04-a
  namespace: demo
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  gracePeriod: 0

Create `tests/04-b-pod-kill.yaml`

Save the second fault as tests/04-b-pod-kill.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-04-b
  namespace: demo
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-1-1
  gracePeriod: 0

Create `tests/04-c-pod-kill.yaml`

Save the third fault as tests/04-c-pod-kill.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-04-c
  namespace: demo
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-1
  gracePeriod: 0

What this chaos does: Kills three different data replicas one at a time, with 20 seconds between injections.

Expected behavior: Every killed pod should be replaced before the next fault is injected. Replication queues, restarts, and checksums should return to baseline after the sequence.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

Keep the workload running while observing the fault and recovery transition.

Apply the files one at a time. Wait 20 seconds between kills, delete each one-shot PodChaos after AllInjected, and run the complete recovery gate after the third kill.

➤ kubectl apply -f tests/04-a-pod-kill.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-04-a created

➤ kubectl wait -n demo --for=condition=AllInjected \
        -f tests/04-a-pod-kill.yaml --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-04-a condition met

➤ kubectl delete -f tests/04-a-pod-kill.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-04-a" deleted from demo namespace

➤ kubectl wait -n demo --for=condition=Ready \
        pod/clickhouse-chaos-chaos-cluster-shard-0-0 --timeout=5m
pod/clickhouse-chaos-chaos-cluster-shard-0-0 condition met

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-0-0 \
        -o jsonpath='{.metadata.uid}{"\n"}'
add2a88c-ed3c-46f3-bbb4-b2cb61fec420

Before starting the next fault, compare both shard-0 replicas:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
7810  7810  18036471919944389959

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
7810  7810  18036471919944389959

➤ kubectl apply -f tests/04-b-pod-kill.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-04-b created

➤ kubectl wait -n demo --for=condition=AllInjected \
        -f tests/04-b-pod-kill.yaml --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-04-b condition met

➤ kubectl delete -f tests/04-b-pod-kill.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-04-b" deleted from demo namespace

➤ kubectl wait -n demo --for=condition=Ready \
        pod/clickhouse-chaos-chaos-cluster-shard-1-1 --timeout=5m
pod/clickhouse-chaos-chaos-cluster-shard-1-1 condition met

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-1-1 \
        -o jsonpath='{.metadata.uid}{"\n"}'
d8da0cb3-168b-40ad-840b-ecb835c27cea

Before starting the third fault, compare both shard-1 replicas:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
8846  8846  12894136727626022465

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
8846  8846  12894136727626022465

➤ kubectl apply -f tests/04-c-pod-kill.yaml

podchaos.chaos-mesh.org/clickhouse-chaos-exp-04-c created

➤ kubectl wait -n demo --for=condition=AllInjected \
        -f tests/04-c-pod-kill.yaml --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-04-c condition met

➤ kubectl delete -f tests/04-c-pod-kill.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-04-c" deleted from demo namespace

➤ kubectl wait -n demo --for=condition=Ready \
        pod/clickhouse-chaos-chaos-cluster-shard-0-1 --timeout=5m
pod/clickhouse-chaos-chaos-cluster-shard-0-1 condition met

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-0-1 \
        -o jsonpath='{.metadata.uid}{"\n"}'
0a753027-af14-428b-8b78-9192f190cfeb

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
204 195 9

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

Shard-0 replica-0, shard-1 replica-1, and shard-0 replica-1 each received a new UID. The explicit SQL, replica-state, and checksum checks passed before each following kill. The workload moved from 134 126 8 to 204 195 9; both replica pairs ended with matching counts and checksums.

Result: PASS — three sequential recoveries did not accumulate replica drift.

Chaos#5: Lose an Entire Shard

Create `tests/05-full-shard-outage.yaml`

Save this YAML as tests/05-full-shard-outage.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-05
  namespace: demo
spec:
  action: pod-failure
  mode: all
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
        - clickhouse-chaos-chaos-cluster-shard-0-1

What this chaos does: Holds both replicas of shard 0 unavailable for 45 seconds.

Expected behavior: Distributed inserts that require shard 0 should fail clearly; the remaining shard cannot substitute for missing shard data. ClickHouse should report Critical, then both replicas should return with equal data.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    19m

Apply this experiment:

➤ kubectl apply -f tests/05-full-shard-outage.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-05 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        podchaos/clickhouse-chaos-exp-05 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-05 condition met

Observe the live impact:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS     AGE
clickhouse-chaos   26.2.6    Critical   20m

Prove that each selected replica is unreachable:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        sh -c 'clickhouse-client --host clickhouse-chaos-chaos-cluster-shard-0-0.clickhouse-chaos-pods.demo.svc --user "$CH_USER" --password "$CH_PASSWORD" --query "SELECT 1"; echo exit_code=$?'
Code: 210. DB::NetException: Connection refused
exit_code=210

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        sh -c 'clickhouse-client --host clickhouse-chaos-chaos-cluster-shard-0-1.clickhouse-chaos-pods.demo.svc --user "$CH_USER" --password "$CH_PASSWORD" --query "SELECT 1"; echo exit_code=$?'
Code: 210. DB::NetException: Connection refused
exit_code=210

Run a Distributed query from the healthy shard. It fails explicitly because the unavailable shard cannot be silently skipped:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count() FROM chaos_v2.events"'
Code: 279. DB::Exception: All connection tries failed. (ALL_CONNECTION_TRIES_FAILED)
command terminated with exit code 279

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
        podchaos/clickhouse-chaos-exp-05 --timeout=2m
podchaos.chaos-mesh.org/clickhouse-chaos-exp-05 condition met

Delete the experiment:

➤ kubectl delete -f tests/05-full-shard-outage.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-05" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1491 1441 50

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
72274	72274	17024341840210372511

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- \
        bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
72274	72274	17024341840210372511

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

Both shard-0 replicas were unavailable. Direct queries returned Connection refused, a Distributed query from shard 1 returned ALL_CONNECTION_TRIES_FAILED, and ClickHouse became Critical. At the recovery checkpoint the workload was 1491 1441 50; both replicas then matched at 72274 rows with queue 0.

Result: PASS — loss of a complete shard caused an explicit outage and recovered without silent inconsistency.

Chaos#6: Lose the Entire ClickHouse Data Plane

Create `tests/06-data-plane-outage.yaml`

Save this YAML as tests/06-data-plane-outage.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-06
  namespace: demo
spec:
  action: pod-failure
  mode: all
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
        - clickhouse-chaos-chaos-cluster-shard-0-1
        - clickhouse-chaos-chaos-cluster-shard-1-0
        - clickhouse-chaos-chaos-cluster-shard-1-1

What this chaos does: Makes all four ClickHouse data pods unavailable while leaving the three Keeper members running.

Expected behavior: SQL clients should see a complete outage and no batch should be acknowledged during it. When the fault ends, all four replicas should reopen their existing PVC data and converge automatically.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    36m

Apply this experiment:

➤ kubectl apply -f tests/06-data-plane-outage.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-06 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        podchaos/clickhouse-chaos-exp-06 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-06 condition met

Observe the live impact:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS     AGE
clickhouse-chaos   26.2.6    Critical   36m

Prove that the SQL service is unavailable:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        sh -c 'clickhouse-client --host clickhouse-chaos.demo.svc --user "$CH_USER" --password "$CH_PASSWORD" --query "SELECT 1"; echo exit_code=$?'
Code: 210. DB::NetException: Connection refused (clickhouse-chaos.demo.svc:9000). (NETWORK_ERROR)
exit_code=210

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
        podchaos/clickhouse-chaos-exp-06 --timeout=2m
podchaos.chaos-mesh.org/clickhouse-chaos-exp-06 condition met

Delete the experiment:

➤ kubectl delete -f tests/06-data-plane-outage.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-06" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1531 1441 90

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

All four data containers were failed while Keeper stayed online. The service query returned Connection refused, ClickHouse became Critical, and the workload moved from 1491 1441 50 to 1531 1441 90: 40 attempts, no acknowledgements. All four pods reopened their existing PVCs and ClickHouse returned to Ready.

Result: PASS — the full data-plane outage was recoverable and did not lose acknowledged rows.

Chaos#7: Kill a Keeper Follower

Discover the Keeper roles immediately before the test.

Create `tests/07-keeper-follower-kill.yaml`

Save this YAML as tests/07-keeper-follower-kill.yaml, using a current follower as the target:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-07
  namespace: demo
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-keeper-1
  gracePeriod: 0

What this chaos does: Discovers the Keeper roles with mntr, then abruptly kills one current follower.

Expected behavior: The leader and remaining follower still form a two-member majority, so coordination and writes should continue. The recreated member should rejoin as a follower.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

The example uses keeper-1; replace it if mntr reports that member as the leader.

Demonstrate impact and recovery

Confirm the role of each Keeper member before selecting the follower:

➤ kubectl exec -n demo clickhouse-chaos-keeper-0 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
leader

➤ kubectl exec -n demo clickhouse-chaos-keeper-1 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

➤ kubectl exec -n demo clickhouse-chaos-keeper-2 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

Record the selected follower UID:

➤ kubectl get pod -n demo clickhouse-chaos-keeper-1 -o jsonpath='{.metadata.uid}{"\n"}'
2eb512bc-c64f-448e-a6bc-ad43cdaffa82

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    37m

Apply this experiment:

➤ kubectl apply -f tests/07-keeper-follower-kill.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-07 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        podchaos/clickhouse-chaos-exp-07 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-07 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-keeper-0 -c clickhouse-keeper -- \
        bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | \
        awk '$1=="zk_server_state" {print $2}'
leader

Delete the experiment:

➤ kubectl delete -f tests/07-keeper-follower-kill.yaml

podchaos.chaos-mesh.org "clickhouse-chaos-exp-07" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing.

➤ kubectl get pod -n demo clickhouse-chaos-keeper-1 -o jsonpath='{.metadata.uid}{" "}{.status.phase}{"\n"}'
cd8ef14e-548d-4bd6-8784-8c964cf877eb Running

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1557 1467 90

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

Keeper-1 was verified as a follower before it was killed. Its UID changed from 2eb512bc-c64f-448e-a6bc-ad43cdaffa82 to cd8ef14e-548d-4bd6-8784-8c964cf877eb; Keeper-0 remained leader, ClickHouse stayed Ready, and all 26 new attempts were acknowledged.

Result: PASS — the remaining two Keeper members retained quorum.

Chaos#8: Kill the Keeper Leader

Rediscover the Keeper roles immediately before the test.

Create `tests/08-keeper-leader-kill.yaml`

Save this YAML as tests/08-keeper-leader-kill.yaml, using the current leader as the target:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-08
  namespace: demo
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-keeper-0
  gracePeriod: 0

What this chaos does: Discovers and kills the current Keeper leader.

Expected behavior: The two surviving members should elect a new leader quickly. ClickHouse should tolerate the short election, and the old leader should return as a follower rather than forming a second leader.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

Keep the workload running while observing the fault and recovery transition.

The example uses keeper-0; replace it with the actual leader. Time how long another member takes to report leader.

Demonstrate impact and recovery

Before injection, verify that Keeper-0 is the leader:

➤ kubectl exec -n demo clickhouse-chaos-keeper-0 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
leader

Record its UID:

➤ kubectl get pod -n demo clickhouse-chaos-keeper-0 -o jsonpath='{.metadata.uid}{"\n"}'
2a540a7e-dbad-4fd6-a7b1-f57d75d7a643

Confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos

NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    38m

Apply this experiment:

➤ kubectl apply -f tests/08-keeper-leader-kill.yaml

podchaos.chaos-mesh.org/clickhouse-chaos-exp-08 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        podchaos/clickhouse-chaos-exp-08 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-08 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-keeper-1 -c clickhouse-keeper -- \
        bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | \
        awk '$1=="zk_server_state" {print $2}'
leader

Delete the experiment:

➤ kubectl delete -f tests/08-keeper-leader-kill.yaml

podchaos.chaos-mesh.org "clickhouse-chaos-exp-08" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Confirm the recovered quorum one member at a time:

➤ kubectl exec -n demo clickhouse-chaos-keeper-0 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

➤ kubectl exec -n demo clickhouse-chaos-keeper-1 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
leader

➤ kubectl exec -n demo clickhouse-chaos-keeper-2 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing.

➤ kubectl get pod -n demo clickhouse-chaos-keeper-0 -o jsonpath='{.metadata.uid}{" "}{.status.phase}{"\n"}'
838451cd-cc02-42b5-8a5c-fbc023c33d9d Running

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1567 1476 91

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

Keeper-0 was the leader before injection. Its UID changed from 2a540a7e-dbad-4fd6-a7b1-f57d75d7a643 to 838451cd-cc02-42b5-8a5c-fbc023c33d9d; Keeper-1 became leader and the other two members reported follower. ClickHouse stayed Ready.

Result: PASS — Keeper elected a new leader automatically.

Chaos#9: Lose Keeper Quorum

Create `tests/09-keeper-quorum-loss.yaml`

Save this YAML as tests/09-keeper-quorum-loss.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-09
  namespace: demo
spec:
  action: pod-failure
  mode: all
  duration: 90s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-keeper-0
        - clickhouse-chaos-keeper-2

What this chaos does: Holds two of the three Keeper members failed for 90 seconds, removing the majority required for coordination.

Expected behavior: Existing reads may continue, but coordination-dependent writes or replication can stall or fail. After quorum returns, queued work should settle and both replicas of every shard should converge without data repair.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Do not repair a brief replica mismatch while queues are still moving. Require two consecutive equal checks within ten minutes.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    42m

Apply this experiment:

➤ kubectl apply -f tests/09-keeper-quorum-loss.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-09 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        podchaos/clickhouse-chaos-exp-09 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-09 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-keeper-1 -c clickhouse-keeper -- \
        bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3'
This instance is not currently serving requests

Prove a coordination-dependent write stalls instead of being acknowledged:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'timeout 8 clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "INSERT INTO chaos_v2.events_local VALUES (generateUUIDv4(), now(), 9)"; echo exit_code=$?'
exit_code=124

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
        podchaos/clickhouse-chaos-exp-09 --timeout=2m
podchaos.chaos-mesh.org/clickhouse-chaos-exp-09 condition met

Delete the experiment:

➤ kubectl delete -f tests/09-keeper-quorum-loss.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-09" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Verify that the recovered replica queue is empty:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT is_readonly, is_session_expired, queue_size, total_replicas, active_replicas FROM system.replicas WHERE database='\''chaos_v2'\'' AND table='\''events_local'\''"'
0  0  0  2  2

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1611 1513 97

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

Keeper-0 and Keeper-2 were selected together for 90 seconds. The lone Keeper-1 returned This instance is not currently serving requests, and a replicated insert timed out with exit code 124. ClickHouse still showed Ready; recovery restored an empty replica queue.

Result: PASS — Keeper quorum reformed and all replica queues drained.

Chaos#10: Fail All Keeper Members

Create `tests/10-full-keeper-outage.yaml`

Save this YAML as tests/10-full-keeper-outage.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-10
  namespace: demo
spec:
  action: pod-failure
  mode: all
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-keeper-0
        - clickhouse-chaos-keeper-1
        - clickhouse-chaos-keeper-2

What this chaos does: Holds all three Keeper members unavailable for 45 seconds.

Expected behavior: ClickHouse processes can remain reachable, but Keeper operations should be unavailable and replicated writes may fail. Recovery requires a new one-leader/two-follower quorum and drained replica queues.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

During injection, check mntr directly even if ClickHouse still reports Ready.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    43m

Apply this experiment:

➤ kubectl apply -f tests/10-full-keeper-outage.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-10 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        podchaos/clickhouse-chaos-exp-10 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-10 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-keeper-0 -c clickhouse-keeper -- \
        bash -c 'printf "mntr\n"'
error: Internal error occurred: Internal error occurred: error executing command in container: failed to exec in container: failed to start exec "628453296b89642b1b9551dfba67fe273943dc7f77f1bd17c3c2ae9965933a96": OCI runtime exec failed: exec failed: unable to start container process: exec: "bash": executable file not found in $PATH

Prove a replicated write cannot complete without Keeper:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'timeout 8 clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "INSERT INTO chaos_v2.events_local VALUES (generateUUIDv4(), now(), 10)"; echo exit_code=$?'
exit_code=124

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
        podchaos/clickhouse-chaos-exp-10 --timeout=2m
podchaos.chaos-mesh.org/clickhouse-chaos-exp-10 condition met

Delete the experiment:

➤ kubectl delete -f tests/10-full-keeper-outage.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-10" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Confirm that Keeper formed one leader and two followers again:

➤ kubectl exec -n demo clickhouse-chaos-keeper-0 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
leader

➤ kubectl exec -n demo clickhouse-chaos-keeper-1 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

➤ kubectl exec -n demo clickhouse-chaos-keeper-2 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1618 1517 100

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

AllInjected=True selected all three Keeper pods, the sampled Keeper-0 exec was rejected while the fault was active, and a replicated insert timed out with exit code 124. ClickHouse data processes remained present and ClickHouse still showed Ready. Keeper returned with one leader and two followers.

Result: PASS — a complete coordination outage recovered automatically.

Network Chaos

Chaos#11: Add Network Delay

Create `tests/11-network-delay.yaml`

Save this YAML as tests/11-network-delay.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: clickhouse-chaos-exp-11
  namespace: demo
spec:
  action: delay
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  direction: to
  delay:
    latency: 500ms
    jitter: 50ms
    correlation: "50"

What this chaos does: Adds 500 ms latency with 50 ms jitter to traffic reaching one data replica for 45 seconds.

Expected behavior: Queries may slow down, but TCP and the healthy replica should keep the tested workload available. The target must finish with no replication delay or queued work.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    45m

Apply this experiment:

➤ kubectl apply -f tests/11-network-delay.yaml
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-11 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        networkchaos/clickhouse-chaos-exp-11 --timeout=90s
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-11 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        ping -c 5 -W 2 10.42.0.42
5 packets transmitted, 5 packets received, 0% packet loss
round-trip min/avg/max = 468.815/517.919/548.130 ms

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
        networkchaos/clickhouse-chaos-exp-11 --timeout=2m
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-11 condition met

Delete the experiment:

➤ kubectl delete -f tests/11-network-delay.yaml
networkchaos.chaos-mesh.org "clickhouse-chaos-exp-11" deleted from demo namespace

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- ping -c 5 -W 2 10.42.0.42
5 packets transmitted, 5 packets received, 0% packet loss
round-trip min/avg/max = 0.049/0.070/0.087 ms

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing. Record the stable counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1633 1532 100

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

Ping average rose from 0.113 ms to 517.919 ms under the configured delay and returned to 0.070 ms after cleanup. ClickHouse remained Ready; the counters moved from 1618 1517 100 to 1633 1532 100, so all 15 new attempts were acknowledged. The target finished writable with queue 0.

Result: PASS — the healthy sibling and TCP retries absorbed the delay.

Chaos#12: Drop 30 Percent of Packets

Create `tests/12-network-loss.yaml`

Save this YAML as tests/12-network-loss.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: clickhouse-chaos-exp-12
  namespace: demo
spec:
  action: loss
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  direction: to
  loss:
    loss: "30"
    correlation: "25"

What this chaos does: Drops 30 percent of packets sent to one ClickHouse replica.

Expected behavior: TCP retransmission should absorb some loss. Timeouts are acceptable, but after the fault the replica must be writable, caught up, and byte-for-byte equivalent at the logical checksum level.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    46m

Apply this experiment:

➤ kubectl apply -f tests/12-network-loss.yaml
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-12 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        networkchaos/clickhouse-chaos-exp-12 --timeout=90s
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-12 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        ping -c 20 -W 1 10.42.0.42
20 packets transmitted, 13 packets received, 35% packet loss
round-trip min/avg/max = 0.063/0.082/0.120 ms

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
        networkchaos/clickhouse-chaos-exp-12 --timeout=2m
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-12 condition met

Delete the experiment:

➤ kubectl delete -f tests/12-network-loss.yaml
networkchaos.chaos-mesh.org "clickhouse-chaos-exp-12" deleted from demo namespace

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- ping -c 5 -W 2 10.42.0.42
5 packets transmitted, 5 packets received, 0% packet loss
round-trip min/avg/max = 0.045/0.106/0.234 ms

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing. Record the stable counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1658 1558 100

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

The 20-packet probe received 13 replies and reported 35% packet loss; the post-recovery probe received all five replies. ClickHouse remained Ready, the workload advanced to 1658 1558 100, and the target finished writable with queue 0.

Result: PASS — packet loss caused no lasting replica damage.

Chaos#13: Duplicate 50 Percent of Packets

Create `tests/13-network-duplicate.yaml`

Save this YAML as tests/13-network-duplicate.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: clickhouse-chaos-exp-13
  namespace: demo
spec:
  action: duplicate
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  direction: to
  duplicate:
    duplicate: "50"
    correlation: "25"

What this chaos does: Duplicates 50 percent of packets reaching one data replica.

Expected behavior: TCP and ClickHouse should not turn duplicated network packets into duplicated table rows. count() must still equal uniqExact(id) after recovery.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    48m

Apply this experiment:

➤ kubectl apply -f tests/13-network-duplicate.yaml
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-13 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        networkchaos/clickhouse-chaos-exp-13 --timeout=90s
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-13 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        ping -c 20 -W 1 10.42.0.42
20 packets transmitted, 20 packets received, 8 duplicates, 0% packet loss
round-trip min/avg/max = 0.049/0.082/0.140 ms

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
        networkchaos/clickhouse-chaos-exp-13 --timeout=2m
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-13 condition met

Delete the experiment:

➤ kubectl delete -f tests/13-network-duplicate.yaml
networkchaos.chaos-mesh.org "clickhouse-chaos-exp-13" deleted from demo namespace

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
80556	80556	11545698640526106827

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
80556	80556	11545698640526106827

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing. Record the stable counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1697 1597 100

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

The 20-packet probe reported eight DUP! replies. After recovery, both shard-0 replicas returned 80556 rows, 80556 unique IDs, and the same checksum.

Result: PASS — network duplication did not create duplicate table rows.

Chaos#14: Limit Bandwidth to 1 Mbps

Create `tests/14-bandwidth.yaml`

Save this YAML as tests/14-bandwidth.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: clickhouse-chaos-exp-14
  namespace: demo
spec:
  action: bandwidth
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-workload-64d7d5c85f-fqjdp
  direction: both
  target:
    mode: all
    selector:
      namespaces:
        - demo
      pods:
        demo:
          - clickhouse-chaos-chaos-cluster-shard-0-0
  bandwidth:
    rate: 1mbps
    limit: 20971520
    buffer: 10000

What this chaos does: Restricts inbound traffic to one replica to 1 Mbps for 45 seconds.

Expected behavior: Throughput and latency may degrade. The client may timeout if demand exceeds the cap, but replication should drain completely after normal bandwidth returns.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    49m

Apply this experiment:

➤ kubectl apply -f tests/14-bandwidth.yaml
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-14 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        networkchaos/clickhouse-chaos-exp-14 --timeout=90s
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-14 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c \
        '/usr/bin/time -f "elapsed=%e" clickhouse-client --host 10.42.0.42 --user "$CH_USER" --password "$CH_PASSWORD" --compression=0 --query "SELECT hex(randomString(450000)) FROM numbers(5) FORMAT TSV" >/dev/null'
elapsed=4.80

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
        networkchaos/clickhouse-chaos-exp-14 --timeout=2m
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-14 condition met

Delete the experiment:

➤ kubectl delete -f tests/14-bandwidth.yaml
networkchaos.chaos-mesh.org "clickhouse-chaos-exp-14" deleted from demo namespace

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c \
        '/usr/bin/time -f "elapsed=%e" clickhouse-client --host 10.42.0.42 --user "$CH_USER" --password "$CH_PASSWORD" --compression=0 --query "SELECT hex(randomString(450000)) FROM numbers(5) FORMAT TSV" >/dev/null'
elapsed=0.21

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing. Record the stable counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1849 1749 100

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

With compression disabled, the same 4.5 MB response took 4.80s under the 1 Mbps cap and 0.21s after recovery. The workload moved from 1729 1629 100 to 1849 1749 100, and the replication queue was empty afterward.

Result: PASS — the workload fit within the constrained link and recovered cleanly.

Chaos#15: Partition One Replica from Data Peers

Create `tests/15-data-partition.yaml`

Save this YAML as tests/15-data-partition.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: clickhouse-chaos-exp-15
  namespace: demo
spec:
  action: partition
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  direction: both
  target:
    mode: all
    selector:
      namespaces:
        - demo
      pods:
        demo:
          - clickhouse-chaos-chaos-cluster-shard-0-1
          - clickhouse-chaos-chaos-cluster-shard-1-0
          - clickhouse-chaos-chaos-cluster-shard-1-1

What this chaos does: Isolates shard-0 replica-0 in both directions from the other three ClickHouse data pods.

Expected behavior: The isolated replica can fall behind while its sibling serves the shard. After reconnection it should fetch missing parts and match the sibling without deleting its pod or PVC.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
        -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    8h

Apply this experiment:

➤ kubectl apply -f tests/15-data-partition.yaml
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-15 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
        networkchaos/clickhouse-chaos-exp-15 --timeout=90s
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-15 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'timeout 3 bash -c "</dev/tcp/10.42.0.44/9000"; echo exit_code=$?'
exit_code=124

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id) FROM chaos_v2.events_local; SELECT queue_size FROM system.replicas WHERE database='\''chaos_v2'\''"'
88120	88120
12

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- \
        bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id) FROM chaos_v2.events_local; SELECT queue_size FROM system.replicas WHERE database='\''chaos_v2'\''"'
88532	88532
0

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
        networkchaos/clickhouse-chaos-exp-15 --timeout=2m
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-15 condition met

Delete the experiment:

➤ kubectl delete -f tests/15-data-partition.yaml
networkchaos.chaos-mesh.org "clickhouse-chaos-exp-15" deleted from demo namespace

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c 'timeout 3 bash -c "</dev/tcp/10.42.0.44/9000"; echo exit_code=$?'
exit_code=0

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local; SELECT queue_size FROM system.replicas WHERE database='\''chaos_v2'\''"'
89357	89357	2709723990317646529
0

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local; SELECT queue_size FROM system.replicas WHERE database='\''chaos_v2'\''"'
89357	89357	2709723990317646529
0

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
        clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
        touch /state/pause

The command prints nothing. Record the stable counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1875 1773 102

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

Peer TCP changed from exit code 0 to timeout exit code 124. During isolation, replica-0 had 88120 rows and queue 12 while its sibling had 88532 rows and queue 0. Without SYSTEM SYNC REPLICA, both automatically converged to 89357 rows with the same checksum and queue 0. The workload ended at 1875 1773 102.

Result: PASS — the isolated replica fetched missing work and converged.

Chaos#16: Partition One Replica from Keeper

Create `tests/16-keeper-partition.yaml`

Save this YAML as tests/16-keeper-partition.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: clickhouse-chaos-exp-16
  namespace: demo
spec:
  action: partition
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  direction: both
  target:
    mode: all
    selector:
      namespaces:
        - demo
      pods:
        demo:
          - clickhouse-chaos-keeper-0
          - clickhouse-chaos-keeper-1
          - clickhouse-chaos-keeper-2

What this chaos does: Blocks one data replica from communicating with all three Keeper members for 45 seconds.

Expected behavior: An existing Keeper session may mask a short partition. If the session expires, replicated-table operations on that replica should stop safely rather than accept uncoordinated state. It should become writable again after reconnection.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS
clickhouse-chaos   26.2.6    Ready

Apply this experiment:

➤ kubectl apply -f tests/16-keeper-partition.yaml
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-16 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
  networkchaos/clickhouse-chaos-exp-16 --timeout=90s
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-16 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT is_readonly, is_session_expired, queue_size FROM system.replicas \
  WHERE database='\''chaos_v2'\'' AND table='\''events_local'\'' FORMAT TSV"'
1  1  0

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'timeout 8 clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "INSERT INTO chaos_v2.events_local VALUES (generateUUIDv4(), now(), 16)"; echo exit_code=$?'
exit_code=124

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  networkchaos/clickhouse-chaos-exp-16 --timeout=2m
networkchaos.chaos-mesh.org/clickhouse-chaos-exp-16 condition met

Delete the experiment:

➤ kubectl delete -f tests/16-keeper-partition.yaml
networkchaos.chaos-mesh.org "clickhouse-chaos-exp-16" deleted from demo namespace

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c 'timeout 3 bash -c "</dev/tcp/10.42.0.46/9181"; echo exit_code=$?'
exit_code=0

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT is_readonly, is_session_expired, queue_size, total_replicas, active_replicas FROM system.replicas WHERE database='\''chaos_v2'\''"'
0	0	0	2	2

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing. Record the stable counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1889 1784 105

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

The target lost all Keeper connectivity. After 20 seconds it reported is_readonly=1 and is_session_expired=1, correctly refusing uncoordinated replicated writes. After cleanup it returned is_readonly=0, queue_size=0, and active_replicas=2. The workload ended at 1889 1784 105.

Result: PASS — Keeper session loss failed safely and recovered automatically.

Resource Stress

Chaos#17: Stress CPU

Create `tests/17-cpu-stress.yaml`

Save this YAML as tests/17-cpu-stress.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: StressChaos
metadata:
  name: clickhouse-chaos-exp-17
  namespace: demo
spec:
  mode: one
  duration: 60s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  containerNames:
    - clickhouse
  stressors:
    cpu:
      workers: 2
      load: 80

What this chaos does: Runs two stress workers at 80 percent CPU load in one ClickHouse container for 60 seconds.

Expected behavior: Latency can increase, but Kubernetes should not restart the pod merely because CPU is throttled. Writes and replication should recover with no lasting queue.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS
clickhouse-chaos   26.2.6    Ready

Record the CPU limit and baseline throttling counters:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'cat /sys/fs/cgroup/cpu.max; grep -E "usage_usec|nr_throttled|throttled_usec" /sys/fs/cgroup/cpu.stat'
100000 100000
usage_usec 117916959
nr_throttled 203
throttled_usec 23817473

Record the restart count before stress:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-0-0 \
  -o jsonpath='{.status.containerStatuses[0].restartCount}{"\n"}'
4

Apply this experiment:

➤ kubectl apply -f tests/17-cpu-stress.yaml
stresschaos.chaos-mesh.org/clickhouse-chaos-exp-17 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
  stresschaos/clickhouse-chaos-exp-17 --timeout=90s
stresschaos.chaos-mesh.org/clickhouse-chaos-exp-17 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        bash -c 'ps -eo pid,pcpu,comm | grep -E "stress-ng|clickhouse" | head; grep -E "usage_usec|nr_throttled|throttled_usec" /sys/fs/cgroup/cpu.stat'
      1 10.4 clickhouse-serv
   1249 44.2 stress-ng-cpu
   1250 44.2 stress-ng-cpu
usage_usec 143313148
nr_throttled 455
throttled_usec 58200837

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  stresschaos/clickhouse-chaos-exp-17 --timeout=2m
stresschaos.chaos-mesh.org/clickhouse-chaos-exp-17 condition met

Delete the experiment:

➤ kubectl delete -f tests/17-cpu-stress.yaml
stresschaos.chaos-mesh.org "clickhouse-chaos-exp-17" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Verify that CPU stress did not restart ClickHouse:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-0-0 \
  -o jsonpath='{.status.containerStatuses[0].restartCount}{"\n"}'
4

Verify that the replication queue is empty:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT queue_size FROM system.replicas WHERE database='\''chaos_v2'\'' AND table='\''events_local'\''"'
0

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing. Record the stable counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1940 1835 105

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

Two CPU workers each consumed about 44% CPU. Cgroup throttling rose from 203 to 455 periods and from 23,817,473 to 58,200,837 microseconds. The target restart count remained 4, ClickHouse stayed Ready, the replication queue returned to 0, and the workload ended at 1940 1835 105.

Result: PASS — CPU throttling increased without restarting ClickHouse or damaging replication.

Chaos#18: Stress Memory

Create `tests/18-memory-stress.yaml`

Save this YAML as tests/18-memory-stress.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: StressChaos
metadata:
  name: clickhouse-chaos-exp-18
  namespace: demo
spec:
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-1-0
  containerNames:
    - clickhouse
  stressors:
    memory:
      workers: 1
      size: 1GiB

What this chaos does: Allocates an additional 1GiB in a ClickHouse pod whose memory limit is 4GiB.

Expected behavior: This test should create strong pressure without intentionally forcing an OOM kill. The process should remain alive and cgroup usage should fall after cleanup. A restart or sustained near-limit usage would fail the test.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy and record the cgroup baseline:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS
clickhouse-chaos   26.2.6    Ready

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c '
  printf "memory_current="; cat /sys/fs/cgroup/memory.current
  printf "memory_max="; cat /sys/fs/cgroup/memory.max
'
memory_current=1301417984
memory_max=4294967296

Record the restart count before memory stress:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-1-0 \
  -o jsonpath='{.status.containerStatuses[0].restartCount}{"\n"}'
3

Apply this experiment:

➤ kubectl apply -f tests/18-memory-stress.yaml
stresschaos.chaos-mesh.org/clickhouse-chaos-exp-18 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
  stresschaos/clickhouse-chaos-exp-18 --timeout=90s
stresschaos.chaos-mesh.org/clickhouse-chaos-exp-18 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c '
printf "memory_current="; cat /sys/fs/cgroup/memory.current
printf "memory_max="; cat /sys/fs/cgroup/memory.max
ps -o pid,stat,comm -p 1'
memory_current=2407194624
memory_max=4294967296
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

Confirm that the restart count did not change:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-1-0 \
  -o jsonpath='{.status.containerStatuses[0].restartCount}{"\n"}'
3

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  stresschaos/clickhouse-chaos-exp-18 --timeout=2m
stresschaos.chaos-mesh.org/clickhouse-chaos-exp-18 condition met

Delete the experiment and measure recovery:

➤ kubectl delete -f tests/18-memory-stress.yaml
stresschaos.chaos-mesh.org "clickhouse-chaos-exp-18" deleted from demo namespace

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c '
printf "memory_current="; cat /sys/fs/cgroup/memory.current
printf "memory_max="; cat /sys/fs/cgroup/memory.max
ps -o pid,stat,comm -p 1'
memory_current=1358225408
memory_max=4294967296
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing. Record the stable counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
1978 1873 105

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

Before injection, memory usage was 1,301,417,984 bytes against a 4,294,967,296-byte limit. A 1GiB stress worker raised usage to 2,407,194,624 bytes without an OOM or restart. After cleanup it fell to 1,358,225,408 bytes, PID 1 remained Ssl, and the workload ended at 1978 1873 105.

Result: PASS — the 4GiB limit provided safe headroom and memory returned toward baseline.

IO Chaos

Chaos#19: Add Filesystem Latency

Create `tests/19-io-latency.yaml`

Save this YAML as tests/19-io-latency.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: clickhouse-chaos-exp-19
  namespace: demo
spec:
  action: latency
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  containerNames:
    - clickhouse
  volumePath: /var/lib/clickhouse
  path: /var/lib/clickhouse/**/*
  delay: 100ms
  percent: 50

What this chaos does: Uses IOChaos to delay 50 percent of operations below /var/lib/clickhouse by 100 ms for 45 seconds.

Expected behavior: Queries can slow or timeout, but ClickHouse must not lose acknowledged parts. Chaos Mesh must remove its toda FUSE layer and restore the normal data mount when the experiment ends.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS
clickhouse-chaos   26.2.6    Ready

Measure the same read-only operation before injection:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c \
        '/usr/bin/time -f "elapsed=%e" sh -c "find /var/lib/clickhouse/store -type f | head -n 20 | xargs stat >/dev/null"'
elapsed=0.00

Apply this experiment:

➤ kubectl apply -f tests/19-io-latency.yaml
iochaos.chaos-mesh.org/clickhouse-chaos-exp-19 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
  iochaos/clickhouse-chaos-exp-19 --timeout=90s
iochaos.chaos-mesh.org/clickhouse-chaos-exp-19 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  findmnt -T /var/lib/clickhouse
TARGET              SOURCE FSTYPE OPTIONS
/var/lib/clickhouse toda   fuse   rw,nosuid,nodev,relatime,user_id=0,group_id=0

Run the read-only latency probe while the FUSE layer is active:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c \
        '/usr/bin/time -f "elapsed=%e" sh -c "find /var/lib/clickhouse/store -type f | head -n 20 | xargs stat >/dev/null"'
stat: cannot statx '/var/lib/clickhouse/store/...': Transport endpoint is not connected
Command exited with non-zero status 123
elapsed=5.78

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  iochaos/clickhouse-chaos-exp-19 --timeout=2m
iochaos.chaos-mesh.org/clickhouse-chaos-exp-19 condition met

Delete the recovered experiment:

➤ kubectl delete -f tests/19-io-latency.yaml
iochaos.chaos-mesh.org "clickhouse-chaos-exp-19" deleted from demo namespace

Check that Chaos Mesh removed its FUSE layer:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  mount | grep /var/lib/clickhouse
/dev/vda1 on /var/lib/clickhouse type ext4 (rw,relatime,discard,errors=remount-ro,commit=30)

Confirm that PID 1 is still running:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

Wait for ClickHouse recovery after the fault has been removed:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing. Record the stable counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
2014 1890 124

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

IOChaos changed the mount from ext4 to toda; the read-only metadata scan changed from 0.00s to 5.78s and returned explicit transport errors. After AllRecovered, ext4 returned, the scan took 0.00s, PID 1 was already Ssl, and the workload ended at 2014 1890 124.

Result: PASS — the latency was directly visible and Chaos Mesh restored the mount and running process automatically.

Chaos#20: Return Recoverable EIO

Create `tests/20-io-fault.yaml`

Save this YAML as tests/20-io-fault.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: clickhouse-chaos-exp-20
  namespace: demo
spec:
  action: fault
  mode: one
  duration: 30s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-1-0
  containerNames:
    - clickhouse
  volumePath: /var/lib/clickhouse
  path: /var/lib/clickhouse/**/*
  errno: 5
  percent: 10

What this chaos does: Makes 10 percent of selected data-volume operations return errno 5 (EIO) for 30 seconds.

EIO is the operating-system error for an input/output failure. It is recoverable in this experiment because Chaos Mesh returns the error only while the experiment is active; it does not deliberately corrupt stored bytes.

Expected behavior: ClickHouse should expose explicit disk errors rather than silently accepting bad data. Some writes may fail. After injection ends, the normal mount, SQL service, and equal replica checksums must return.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Record the workload counters before applying the experiment. The values are attempted, acknowledged, and failed batches, in that order:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
2014 1890 124

Demonstrate impact and recovery

Before injection, confirm that ClickHouse is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS
clickhouse-chaos   26.2.6    Ready

Confirm that the selected replica is using its normal ext4-backed PVC:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  findmnt -T /var/lib/clickhouse
TARGET              SOURCE                                                                                                                              FSTYPE OPTIONS
/var/lib/clickhouse /dev/vda1[/var/lib/rancher/k3s/storage/pvc-eecf7db8-b9b5-4888-b1aa-71e70ea65119_demo_data-clickhouse-chaos-chaos-cluster-shard-1-0] ext4   rw,relatime,discard,errors=remount-ro,commit=30

Run the read-only probe against existing ClickHouse part files. Before fault injection, it must finish successfully:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  sh -c 'find /var/lib/clickhouse/store -type f -exec stat {} + >/dev/null; echo exit_code=$?'
exit_code=0

Apply this experiment:

➤ kubectl apply -f tests/20-io-fault.yaml
iochaos.chaos-mesh.org/clickhouse-chaos-exp-20 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
  iochaos/clickhouse-chaos-exp-20 --timeout=90s
iochaos.chaos-mesh.org/clickhouse-chaos-exp-20 condition met

While AllInjected=True, inspect the data mount again:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  findmnt -T /var/lib/clickhouse
TARGET              SOURCE FSTYPE OPTIONS
/var/lib/clickhouse toda   fuse   rw,nosuid,nodev,relatime,user_id=0,group_id=0,default_permissions,allow_other

The toda FUSE source proves that Chaos Mesh has interposed its fault layer on the selected mount. Run the same read-only probe again. It performs a metadata lookup for every existing part file, giving the 10 percent fault enough operations to encounter EIO without creating or changing data:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  sh -c 'find /var/lib/clickhouse/store -type f -exec stat {} + >/dev/null; echo exit_code=$?'
find: ‘/var/lib/clickhouse/store’: Input/output error
exit_code=1

This is the direct proof that the experiment worked: the same path was ext4 before injection, became the toda fault mount, and returned Input/output error with a non-zero exit code. AllInjected=True alone would only prove that Chaos Mesh attached the experiment, not that an operation actually encountered the configured error.

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  iochaos/clickhouse-chaos-exp-20 --timeout=2m
iochaos.chaos-mesh.org/clickhouse-chaos-exp-20 condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing. Read the same three workload counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
2040 1903 137

During this test window, the client attempted 26 batches: 13 were acknowledged, and 13 failed or were ambiguous. The counters do not attribute every failure to EIO; the read-only probe proves the configured storage error, while the workload counters prove an availability impact during the same injection window.

Verify that the original filesystem is mounted again:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  findmnt -T /var/lib/clickhouse
TARGET              SOURCE                                                                                                                              FSTYPE OPTIONS
/var/lib/clickhouse /dev/vda1[/var/lib/rancher/k3s/storage/pvc-eecf7db8-b9b5-4888-b1aa-71e70ea65119_demo_data-clickhouse-chaos-chaos-cluster-shard-1-0] ext4   rw,relatime,discard,errors=remount-ro,commit=30

Verify that ClickHouse PID 1 is runnable. Ssl is a normal sleeping server process; importantly, it does not contain T, which would mean stopped:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

Delete the experiment:

➤ kubectl delete -f tests/20-io-fault.yaml
iochaos.chaos-mesh.org "clickhouse-chaos-exp-20" deleted from demo namespace

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Prove the same read-only operation succeeds again after recovery:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  sh -c 'find /var/lib/clickhouse/store -type f -exec stat {} + >/dev/null; echo exit_code=$?'
exit_code=0

The zero exit code proves that the selected filesystem became readable again after the fault.

Observed behavior:

The toda mount returned a real Input/output error to the read-only probe, and the workload recorded failed inserts during the fault window. After AllRecovered, the PVC was ext4 again, PID 1 was Ssl, SQL responded, and the same read-only traversal returned exit code 0. No signal or pod replacement was required.

Result: PASS — the transient EIO was visible, ClickHouse recovered without manual intervention, and the read-only recovery probe passed.

DNS and Time Chaos

Chaos#21: Return Keeper DNS Errors

Create `tests/21-keeper-dns-error.yaml`

Save this YAML as tests/21-keeper-dns-error.yaml. Use the complete .svc.cluster.local names; a pattern ending at .svc does not match the DNS query made by the resolver.

apiVersion: chaos-mesh.org/v1alpha1
kind: DNSChaos
metadata:
  name: clickhouse-chaos-exp-21
  namespace: demo
spec:
  action: error
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  containerNames:
    - clickhouse
  patterns:
    - clickhouse-chaos-keeper-0.clickhouse-chaos-keeper-pods.demo.svc.cluster.local
    - clickhouse-chaos-keeper-1.clickhouse-chaos-keeper-pods.demo.svc.cluster.local
    - clickhouse-chaos-keeper-2.clickhouse-chaos-keeper-pods.demo.svc.cluster.local

What this chaos does: Returns DNS errors for the three full Keeper service FQDNs when queried from one ClickHouse container.

Expected behavior: A direct lookup must fail during injection and succeed afterward. Established Keeper TCP sessions may keep working, so uninterrupted writes do not by themselves prove that DNSChaos failed to inject.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS
clickhouse-chaos   26.2.6    Ready

Prove the target can resolve Keeper before injection:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        getent hosts clickhouse-chaos-keeper-2.clickhouse-chaos-keeper-pods.demo.svc.cluster.local
10.42.0.39      clickhouse-chaos-keeper-2.clickhouse-chaos-keeper-pods.demo.svc.cluster.local

Apply this experiment:

➤ kubectl apply -f tests/21-keeper-dns-error.yaml
dnschaos.chaos-mesh.org/clickhouse-chaos-exp-21 created

Confirm that Chaos Mesh reached the target:

➤ kubectl wait -n demo --for=condition=AllInjected \
  dnschaos/clickhouse-chaos-exp-21 --timeout=90s
dnschaos.chaos-mesh.org/clickhouse-chaos-exp-21 condition met

Observe the live impact:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  getent hosts clickhouse-chaos-keeper-2.clickhouse-chaos-keeper-pods.demo.svc.cluster.local
command terminated with exit code 2

The sibling is the control and must still resolve the same name:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- \
        sh -c 'getent hosts clickhouse-chaos-keeper-2.clickhouse-chaos-keeper-pods.demo.svc.cluster.local; echo exit_code=$?'
10.42.0.39      clickhouse-chaos-keeper-2.clickhouse-chaos-keeper-pods.demo.svc.cluster.local
exit_code=0

Wait for Chaos Mesh to remove the fault:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  dnschaos/clickhouse-chaos-exp-21 --timeout=2m
dnschaos.chaos-mesh.org/clickhouse-chaos-exp-21 condition met

Delete the experiment:

➤ kubectl delete -f tests/21-keeper-dns-error.yaml
dnschaos.chaos-mesh.org "clickhouse-chaos-exp-21" deleted from demo namespace

Prove DNS recovery on the original target:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
        sh -c 'getent hosts clickhouse-chaos-keeper-2.clickhouse-chaos-keeper-pods.demo.svc.cluster.local; echo exit_code=$?'
10.42.0.39      clickhouse-chaos-keeper-2.clickhouse-chaos-keeper-pods.demo.svc.cluster.local
exit_code=0

Wait for ClickHouse to report full recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing.

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
2079 1942 137

Observed behavior:

Before injection, the Keeper FQDN resolved to 10.42.0.39. During DNSChaos, the target returned exit code 2 while the sibling resolved the same name with exit code 0. After recovery, the target resolved it again; the workload moved from 2040 1903 137 to 2079 1942 137.

Result: PASS — the DNS fault was proved independently from cached coordination connections.

Chaos#22: Skew the Clock Back Two Hours

Create `tests/22-clock-skew.yaml`

Save this YAML as tests/22-clock-skew.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: TimeChaos
metadata:
  name: clickhouse-chaos-exp-22
  namespace: demo
spec:
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-1-1
  containerNames:
    - clickhouse
  timeOffset: -2h
  clockIds:
    - CLOCK_REALTIME

What this chaos does: Changes only CLOCK_REALTIME for one ClickHouse process by minus two hours for 45 seconds. It simulates a node with badly incorrect wall-clock synchronization without changing the control replica’s clock.

Expected behavior: The target’s now() values and log timestamps should move two hours backward while the control replica remains correct. ClickHouse should continue serving data, replication should converge, and no unique ID should be lost or duplicated. When the fault expires, Chaos Mesh should restore the clock automatically and leave PID 1 running; no manual signal or pod restart should be necessary.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

An incorrect timezone and an incorrect clock are different conditions. A wrong timezone normally changes only how local time is displayed; the underlying UTC clock remains correct, and ClickHouse can continue functioning. An actual two-hour clock error changes the time returned by now() and can affect inserted timestamps, TTL processing, scheduled work, logs, certificate validation, and other time-based behavior. This experiment changes one ClickHouse process’s real-time clock. It does not change the node timezone.

Record the target and control clocks before applying the fault:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c \
        'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT now(), toUnixTimestamp(now())"'
2026-09-09 09:20:47	1788945647

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c \
        'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT now(), toUnixTimestamp(now())"'
2026-09-09 09:20:47	1788945647

Validate and apply the fault:

➤ kubectl apply --dry-run=server -f tests/22-clock-skew.yaml
timechaos.chaos-mesh.org/clickhouse-chaos-exp-22 created (server dry run)

➤ kubectl apply -f tests/22-clock-skew.yaml
timechaos.chaos-mesh.org/clickhouse-chaos-exp-22 created

➤ kubectl wait -n demo --for=condition=AllInjected \
  -f tests/22-clock-skew.yaml --timeout=90s
timechaos.chaos-mesh.org/clickhouse-chaos-exp-22 condition met

The target SQL query did not return before the timeout:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- \
  bash -c 'timeout 8 clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT now(), toUnixTimestamp(now())"; echo exit_code=$?'
exit_code=124

Inspect PID 1 to explain the timeout:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- \
        ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Tsl  clickhouse-serv

The control replica continued returning current time:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c \
        'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT now(), toUnixTimestamp(now())"'
2026-09-09 09:21:32	1788945692

Wait for the 45-second fault to finish:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  -f tests/22-clock-skew.yaml --timeout=150s
timechaos.chaos-mesh.org/clickhouse-chaos-exp-22 condition met

➤ kubectl delete -f tests/22-clock-skew.yaml
timechaos.chaos-mesh.org "clickhouse-chaos-exp-22" deleted from demo namespace

After AllRecovered, inspect PID 1:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- \
  ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Tsl  clickhouse-serv

The expected state does not contain T. If it does, Chaos Mesh did not fully clean up the experiment. Resume the existing process and rerun the complete gate:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- \
  kill -CONT 1

kill -CONT printed nothing. Checking PID 1 again produced:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- \
  ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing.

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
2088 1947 140

Observed behavior:

Both replicas returned the same current timestamp before injection. After AllInjected, the target SQL call hung and PID 1 was Tsl; the control replica still returned current time. AllRecovered=True left PID 1 stopped, so kill -CONT 1 was required to restore Ssl. This run did not produce a usable two-hour-skew observation.

Result: CHAOS TOOL LIMITATION — ClickHouse data recovered, but Chaos Mesh stopped the process instead of demonstrating a live skewed clock and required manual SIGCONT cleanup.

Combined Chaos and Recovery Soak

Chaos#23: Combine I/O Latency with Sibling Failure

Create `tests/23-io-plus-sibling-failure.yaml`

Save both resources in tests/23-io-plus-sibling-failure.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: clickhouse-chaos-exp-23-io
  namespace: demo
spec:
  action: latency
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  containerNames:
    - clickhouse
  volumePath: /var/lib/clickhouse
  path: /var/lib/clickhouse/**/*
  delay: 100ms
  percent: 50
---
apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-23-pod
  namespace: demo
spec:
  action: pod-failure
  mode: one
  duration: 45s
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-1

What this chaos does: Adds 100 ms storage latency to shard-0 replica-0 while holding its sibling replica-1 failed.

Expected behavior: This removes the healthy fast path for the shard, so errors and Critical are acceptable. Once both faults clear, the siblings must converge and the IOChaos FUSE mount must disappear without PVC changes.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Demonstrate impact and recovery

Before injection, confirm the database is healthy:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS
clickhouse-chaos   26.2.6    Ready

Apply this experiment:

➤ kubectl apply -f tests/23-io-plus-sibling-failure.yaml
iochaos.chaos-mesh.org/clickhouse-chaos-exp-23-io created
podchaos.chaos-mesh.org/clickhouse-chaos-exp-23-pod created

Confirm that the I/O fault reached replica-0:

➤ kubectl wait -n demo --for=condition=AllInjected \
  iochaos/clickhouse-chaos-exp-23-io --timeout=90s
iochaos.chaos-mesh.org/clickhouse-chaos-exp-23-io condition met

Confirm that the sibling failure reached replica-1:

➤ kubectl wait -n demo --for=condition=AllInjected \
  podchaos/clickhouse-chaos-exp-23-pod --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-23-pod condition met

Observe the live impact:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS
clickhouse-chaos   26.2.6    Critical

Confirm that IOChaos replaced the normal data mount with its toda FUSE layer:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  findmnt -T /var/lib/clickhouse
TARGET              SOURCE FSTYPE OPTIONS
/var/lib/clickhouse toda   fuse   rw,nosuid,nodev,relatime,user_id=0,group_id=0

Prove that the sibling failure also reached its target:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- bash -c 'printf ok'
error: Internal error occurred: OCI runtime exec failed: exec: "bash": executable file not found in $PATH

The service had no healthy path for shard 0:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c \
        'timeout 8 clickhouse-client --host clickhouse-chaos.demo.svc --user "$CH_USER" --password "$CH_PASSWORD" --query "SELECT count() FROM chaos_v2.events"; echo exit_code=$?'
Code: 210. DB::NetException: Connection refused (clickhouse-chaos.demo.svc:9000). (NETWORK_ERROR)
exit_code=210

The workload counters during the combined fault were:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- bash -c '
printf "attempted="; cat /state/attempt_batches
printf "successful="; cat /state/success_batches
printf "failed="; cat /state/failed_batches'
attempted=2121
successful=1949
failed=172

Wait for the I/O fault duration to finish:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  iochaos/clickhouse-chaos-exp-23-io --timeout=2m
iochaos.chaos-mesh.org/clickhouse-chaos-exp-23-io condition met

Wait for the sibling failure duration to finish:

➤ kubectl wait -n demo --for=condition=AllRecovered \
  podchaos/clickhouse-chaos-exp-23-pod --timeout=2m
podchaos.chaos-mesh.org/clickhouse-chaos-exp-23-pod condition met

Delete the PodChaos first:

➤ kubectl delete podchaos -n demo clickhouse-chaos-exp-23-pod
podchaos.chaos-mesh.org "clickhouse-chaos-exp-23-pod" deleted from demo namespace

Delete the IOChaos second:

➤ kubectl delete iochaos -n demo clickhouse-chaos-exp-23-io
iochaos.chaos-mesh.org "clickhouse-chaos-exp-23-io" deleted from demo namespace

Check that the normal filesystem is mounted again:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  mount | grep /var/lib/clickhouse
/dev/vda1 on /var/lib/clickhouse type ext4 (rw,relatime,discard,errors=remount-ro,commit=30)

Check the ClickHouse process state:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  ps -o pid,stat,comm -p 1
    PID STAT COMMAND
      1 Ssl  clickhouse-serv

Unlike experiments 19 and 22, this process was not stopped after cleanup; kill -CONT 1 was not required.

Compare the replicas after automatic recovery:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c \
        'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local; SELECT queue_size FROM system.replicas WHERE database='\''chaos_v2'\''"'
99019	99019	2073066991253321069
0

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- bash -c \
        'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local; SELECT queue_size FROM system.replicas WHERE database='\''chaos_v2'\''"'
99019	99019	2073066991253321069
0

Finally, wait for ClickHouse to return to Ready:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing.

Record the stable counters after recovery:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
2121 1949 172

After any in-flight batch finishes, run the mandatory recovery gate.

Observed behavior:

Shard-0 replica-0 had a toda latency mount and returned delayed transport errors while replica-1 rejected exec. The service query returned Connection refused, ClickHouse became Critical, and the workload ended at 2121 1949 172. Cleanup restored ext4 and PID Ssl; both replicas matched at 99019 rows with queue 0.

Result: PASS — the combined shard fault recovered fully and Chaos Mesh cleanup succeeded this time.

Chaos#24: Run Three Recovery-Soak Cycles

Create `tests/24-1-recovery-soak.yaml`

Save the first cycle as tests/24-1-recovery-soak.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-24-1
  namespace: demo
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-1-0
  gracePeriod: 0

Create `tests/24-2-recovery-soak.yaml`

Save the second cycle as tests/24-2-recovery-soak.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-24-2
  namespace: demo
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-0-0
  gracePeriod: 0

Create `tests/24-3-recovery-soak.yaml`

Save the third cycle as tests/24-3-recovery-soak.yaml:

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: clickhouse-chaos-exp-24-3
  namespace: demo
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    pods:
      demo:
        - clickhouse-chaos-chaos-cluster-shard-1-1
  gracePeriod: 0

What this chaos does: Repeats one-shot pod kills across three replicas, running the complete recovery gate between cycles.

Expected behavior: Every cycle should return to the same healthy baseline. No replication backlog, checksum difference, stopped process, stale FUSE mount, or restart instability may accumulate across cycles.

Resume the workload

Discover the workload pod by its label:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-64d7d5c85f-fqjdp

Resume the workload before injecting the fault:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  rm -f /state/pause

The command prints nothing. Keep the workload running while observing the fault and recovery transition.

Apply the files in numeric order. Each cycle must recover completely before the next pod is killed.

Cycle 1: clickhouse-chaos-chaos-cluster-shard-1-0

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-1-0 \
  -o jsonpath='{.metadata.uid}{"\n"}'
326909c8-1fe4-4c3e-99f8-3c14f8680d4b

Inject the pod kill:

➤ kubectl apply -f tests/24-1-recovery-soak.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-24-1 created

Confirm injection:

➤ kubectl wait -n demo --for=condition=AllInjected \
  podchaos/clickhouse-chaos-exp-24-1 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-24-1 condition met

Delete this one-shot experiment:

➤ kubectl delete -f tests/24-1-recovery-soak.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-24-1" deleted from demo namespace

Wait for this replica:

➤ kubectl wait -n demo --for=condition=Ready \
  pod/clickhouse-chaos-chaos-cluster-shard-1-0 --timeout=5m
pod/clickhouse-chaos-chaos-cluster-shard-1-0 condition met

Run the ClickHouse recovery gate before continuing:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Confirm the replacement UID:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-1-0 \
  -o jsonpath='{.metadata.uid}{"\n"}'
24daa5d8-08ab-48b8-aeec-d417b7f10d27

Verify cycle 1 with SQL on both replicas:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
101256	101256	6139974127982147424

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
101256	101256	6139974127982147424

Cycle 2: clickhouse-chaos-chaos-cluster-shard-0-0

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-0-0 \
  -o jsonpath='{.metadata.uid}{"\n"}'
add2a88c-ed3c-46f3-bbb4-b2cb61fec420

Inject the pod kill:

➤ kubectl apply -f tests/24-2-recovery-soak.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-24-2 created

Confirm injection:

➤ kubectl wait -n demo --for=condition=AllInjected \
  podchaos/clickhouse-chaos-exp-24-2 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-24-2 condition met

Delete this one-shot experiment:

➤ kubectl delete -f tests/24-2-recovery-soak.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-24-2" deleted from demo namespace

Wait for this replica:

➤ kubectl wait -n demo --for=condition=Ready \
  pod/clickhouse-chaos-chaos-cluster-shard-0-0 --timeout=5m
pod/clickhouse-chaos-chaos-cluster-shard-0-0 condition met

Run the ClickHouse recovery gate before continuing:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Confirm the replacement UID:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-0-0 \
  -o jsonpath='{.metadata.uid}{"\n"}'
ce5234f0-f938-4927-9b3b-f9244ab22607

Verify cycle 2 with SQL on both replicas:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
101943	101943	14304192949753297155

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
101943	101943	14304192949753297155

Cycle 3: clickhouse-chaos-chaos-cluster-shard-1-1

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-1-1 \
  -o jsonpath='{.metadata.uid}{"\n"}'
d8da0cb3-168b-40ad-840b-ecb835c27cea

Inject the pod kill:

➤ kubectl apply -f tests/24-3-recovery-soak.yaml
podchaos.chaos-mesh.org/clickhouse-chaos-exp-24-3 created

Confirm injection:

➤ kubectl wait -n demo --for=condition=AllInjected \
  podchaos/clickhouse-chaos-exp-24-3 --timeout=90s
podchaos.chaos-mesh.org/clickhouse-chaos-exp-24-3 condition met

Delete this one-shot experiment:

➤ kubectl delete -f tests/24-3-recovery-soak.yaml
podchaos.chaos-mesh.org "clickhouse-chaos-exp-24-3" deleted from demo namespace

Wait for this replica:

➤ kubectl wait -n demo --for=condition=Ready \
  pod/clickhouse-chaos-chaos-cluster-shard-1-1 --timeout=5m
pod/clickhouse-chaos-chaos-cluster-shard-1-1 condition met

Run the ClickHouse recovery gate before continuing:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

Confirm the replacement UID:

➤ kubectl get pod -n demo clickhouse-chaos-chaos-cluster-shard-1-1 \
  -o jsonpath='{.metadata.uid}{"\n"}'
b4d71c1f-6045-4fe5-93e1-1856b9e511cf

Verify cycle 3 with SQL on both replicas:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
105543	105543	10953483407728974470

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
105543	105543	10953483407728974470

Pause the workload

After capturing the recovery transition, stop the workload from starting new batches:

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- \
  touch /state/pause

The command prints nothing.

➤ kubectl exec -n demo clickhouse-chaos-workload-64d7d5c85f-fqjdp -- sh -c 'paste -d " " /state/attempt_batches /state/success_batches /state/failed_batches'
2225 2053 172

After any in-flight batch finishes, run the mandatory recovery gate and record the stable integrity result.

Observed behavior:

Three one-shot kills replaced shard-1 replica-0, shard-0 replica-0, and shard-1 replica-1. Their new UIDs were 24daa5d8-08ab-48b8-aeec-d417b7f10d27, ce5234f0-f938-4927-9b3b-f9244ab22607, and b4d71c1f-6045-4fe5-93e1-1856b9e511cf. SQL, replica-state, and checksum checks passed between cycles; the workload ended at 2225 2053 172.

Result: PASS — repeated recovery remained stable with no accumulating backlog.

Chaos#25: Delete One Shard Replica and Its PVC

Killing a pod normally preserves its PVC. This experiment deletes one replica’s PVC and pod to simulate permanent loss of that replica’s disk. This experiment uses kubectl directly and does not require Chaos Mesh.

What this chaos does: Removes the local metadata and data files of shard-1 replica-1. Shard-1 replica-0 remains online as the donor. The two replicas of shard 0 remain untouched as a control.

Expected behavior: KubeDB should provision a new 4Gi PVC and pod. The operator should detect that the PVC name is unchanged but its Kubernetes UID changed, keep the old UID in ClickHouse status while recovery is incomplete, remove the stale Keeper registration, recreate the schema from shard-1 replica-0, and allow ReplicatedMergeTree to fetch every part. Only after verifying the rebuilt replica should it store the new PVC UID. No manual table creation, SYSTEM SYNC REPLICA, part attachment, or data copy is allowed.

Pause the workload

Get the workload pod name:

➤ kubectl get pods -n demo -l app=clickhouse-chaos-workload \
  -o jsonpath='{.items[0].metadata.name}{"\n"}'
clickhouse-chaos-workload-6bbd56c5fb-bb8jj

Use that pod name to pause the workload:

➤ kubectl exec -n demo clickhouse-chaos-workload-6bbd56c5fb-bb8jj -- \
  touch /state/pause

The command prints nothing on success. Confirm that no insert is still active:

➤ kubectl exec -n demo clickhouse-chaos-workload-6bbd56c5fb-bb8jj -- bash -c '
if pgrep -x clickhouse-client >/dev/null; then
  echo "client still active"
else
  echo "workload paused"
fi'
workload paused

Record the workload counters:

➤ kubectl exec -n demo clickhouse-chaos-workload-6bbd56c5fb-bb8jj -- bash -c '
printf "attempted="; cat /state/attempt_batches
printf "successful="; cat /state/success_batches
printf "failed="; cat /state/failed_batches'
attempted=32
successful=32
failed=0

Check the Distributed table before deleting anything:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events FORMAT TSV"'
103400  103400  3910055939419697122

In this validation run, the table already contained 100,200 rows before this workload pod started. Its 32 acknowledged batches produced 103,400 rows. Equality between count() and uniqExact(id) proves every ID is unique.

Compare the two shard-1 replicas before the fault. ClickHouse has already synchronized them; no manual synchronization command is needed:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events_local FORMAT TSV"'
51921  51921  4372140365607959779

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events_local FORMAT TSV"'
51921  51921  4372140365607959779

Record the donor pod UID:

➤ kubectl get pod -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 \
  -o jsonpath='{.metadata.uid}{"\n"}'
a6566514-db0c-4056-bd79-db345830acd9

Record the target pod UID:

➤ kubectl get pod -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 \
  -o jsonpath='{.metadata.uid}{"\n"}'
fddf6596-046f-422d-a241-9a2792afcfdb

Record the target PVC UID and PV:

➤ kubectl get pvc -n demo \
  data-clickhouse-chaos-chaos-cluster-shard-1-1 \
  -o jsonpath='{.metadata.uid}{"\n"}{.spec.volumeName}{"\n"}'
fc211692-e490-4494-ab28-b7e94df817f4
pvc-fc211692-e490-4494-ab28-b7e94df817f4

The same UID must already be present in ClickHouse status. This is the last PVC identity whose replica the operator verified:

➤ kubectl get clickhouse -n demo clickhouse-chaos \
  -o go-template='{{index .status.observedDataPVCUIDs "data-clickhouse-chaos-chaos-cluster-shard-1-1"}}{{"\n"}}'
fc211692-e490-4494-ab28-b7e94df817f4

Delete the PVC first. Because the pod still uses it, Kubernetes marks it for deletion but cannot remove the volume yet:

➤ kubectl delete pvc -n demo \
  data-clickhouse-chaos-chaos-cluster-shard-1-1 --wait=false
persistentvolumeclaim "data-clickhouse-chaos-chaos-cluster-shard-1-1" deleted from demo namespace

Delete the consuming pod. This order prevents PetSet from recreating the pod against the old PVC before the deletion request reaches the API server:

➤ kubectl delete pod -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 --wait=false
pod "clickhouse-chaos-chaos-cluster-shard-1-1" deleted from demo namespace

Wait for the replacement pod to become Ready:

➤ kubectl wait -n demo --for=condition=Ready \
  pod/clickhouse-chaos-chaos-cluster-shard-1-1 --timeout=5m
pod/clickhouse-chaos-chaos-cluster-shard-1-1 condition met

The operator gives a newly Ready pod a one-minute startup grace period before treating its missing schema as disk loss. Run the next identity and table checks during that window to observe the impact before repair starts.

The replacement pod has a new UID:

➤ kubectl get pod -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 \
  -o jsonpath='{.metadata.uid}{"\n"}'
0042bd3a-2dae-4515-be6b-c2d84b55812d

The replacement PVC and PV also have new identities:

➤ kubectl get pvc -n demo \
  data-clickhouse-chaos-chaos-cluster-shard-1-1 \
  -o jsonpath='{.metadata.uid}{"\n"}{.spec.volumeName}{"\n"}'
88b3caae-4e64-492a-a1b5-9ff683e0c310
pvc-88b3caae-4e64-492a-a1b5-9ff683e0c310

The old PV no longer exists:

➤ kubectl get pv pvc-fc211692-e490-4494-ab28-b7e94df817f4
Error from server (NotFound): persistentvolumes "pvc-fc211692-e490-4494-ab28-b7e94df817f4" not found

The live PVC UID has changed, but status still contains the old verified UID:

➤ kubectl get clickhouse -n demo clickhouse-chaos \
  -o go-template='{{index .status.observedDataPVCUIDs "data-clickhouse-chaos-chaos-cluster-shard-1-1"}}{{"\n"}}'
fc211692-e490-4494-ab28-b7e94df817f4

Immediately after startup, the new disk has no workload table:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "EXISTS TABLE chaos_v2.events_local"'
0

This proves the old data directory was not reused. ClickHouse becomes NotReady while the operator verifies the replacement and rebuilds it:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS     AGE
clickhouse-chaos   26.2.6    NotReady   14m

Wait for automatic recovery:

➤ kubectl wait -n demo --for=jsonpath='{.status.phase}'=Ready \
  clickhouse/clickhouse-chaos --timeout=5m
clickhouse.kubedb.com/clickhouse-chaos condition met

ClickHouse is healthy again:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    15m

Only after recovery does status advance to the new PVC UID:

➤ kubectl get clickhouse -n demo clickhouse-chaos \
  -o go-template='{{index .status.observedDataPVCUIDs "data-clickhouse-chaos-chaos-cluster-shard-1-1"}}{{"\n"}}'
88b3caae-4e64-492a-a1b5-9ff683e0c310

The table now exists on the rebuilt replica:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "EXISTS TABLE chaos_v2.events_local"'
1

Compare the donor:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events_local FORMAT TSV"'
51921  51921  4372140365607959779

Compare the rebuilt replica:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events_local FORMAT TSV"'
51921  51921  4372140365607959779

The six values below are is_readonly, is_session_expired, queue_size, total_replicas, active_replicas, and absolute_delay:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT is_readonly, is_session_expired, queue_size,
                  total_replicas, active_replicas, absolute_delay
           FROM system.replicas
           WHERE database = '\''chaos_v2'\'' AND table = '\''events_local'\''
           FORMAT TSV"'
0  0  0  2  2  0

The replica is writable, its session is valid, the replication queue is empty, and both replicas are active. The provisioner log identifies both the UID change and the sibling used for recovery:

➤ kubectl logs -n kubedb kubedb-kubedb-provisioner-0 --since=10m | \
  grep -E 'data-clickhouse-chaos-chaos-cluster-shard-1-1|repaired clickhouse-chaos-chaos-cluster-shard-1-1' | tail -n 2
I0916 09:07:38.104993       1 pvc_identity.go:201] "Detected replacement ClickHouse data PVC" clickhouse="demo/clickhouse-chaos" pvc="data-clickhouse-chaos-chaos-cluster-shard-1-1" previousUID="fc211692-e490-4494-ab28-b7e94df817f4" currentUID="88b3caae-4e64-492a-a1b5-9ff683e0c310"
I0916 09:07:38.433647       1 replica_recovery.go:327] replica recovery: repaired clickhouse-chaos-chaos-cluster-shard-1-1 from clickhouse-chaos-chaos-cluster-shard-1-0, created 3 object(s)

Resume and pause the workload

Resume the existing workload to prove new writes still work:

➤ kubectl exec -n demo clickhouse-chaos-workload-6bbd56c5fb-bb8jj -- \
  rm -f /state/pause

The command prints nothing on success. Check its latest results:

➤ kubectl logs -n demo clickhouse-chaos-workload-6bbd56c5fb-bb8jj --tail=3
2026-09-16T09:09:24+00:00 success attempt=39 rows=100
2026-09-16T09:09:25+00:00 success attempt=40 rows=100
2026-09-16T09:09:26+00:00 success attempt=41 rows=100

Pause it again for the final stable check:

➤ kubectl exec -n demo clickhouse-chaos-workload-6bbd56c5fb-bb8jj -- \
  touch /state/pause

The command prints nothing on success.

➤ kubectl exec -n demo clickhouse-chaos-workload-6bbd56c5fb-bb8jj -- bash -c '
printf "attempted="; cat /state/attempt_batches
printf "successful="; cat /state/success_batches
printf "failed="; cat /state/failed_batches'
attempted=48
successful=48
failed=0

The final Distributed-table check includes all 48 acknowledged workload batches and still has one unique UUID per row:

➤ kubectl exec -n demo \
  clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- bash -c '
clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" \
  --query "SELECT count(), uniqExact(id), sum(payload)
           FROM chaos_v2.events FORMAT TSV"'
105000  105000  9881935531731920006

Observed behavior: KubeDB detected the replacement exclusively from the PVC UID change. Status retained the previous UID until the empty replica had been rebuilt from its shard sibling, then advanced to the new UID. The rebuilt replica matched the donor at 51,921 rows, and every post-recovery workload batch shown above succeeded.

Result: PASS — complete loss of one replica’s pod and disk recovered automatically from its sibling without manual schema or data repair.

Chaos Testing Results Summary

#	Fault	Observed impact	Recovery
1	Single replica pod kill	Target UID changed; ClickHouse stayed `Ready`	Both replicas matched at 2,319 rows
2	Replica pod failure, 45s	Direct query refused; target restarted twice; ClickHouse became `Critical`	SQL and `Ready` returned
3	ClickHouse container kill	Same pod UID; restart count 0 → 1	Queue returned to 0
4	Three alternating pod kills	Three target UIDs changed; one ambiguous attempt	SQL and checksum checks passed between kills
5	Both replicas of shard 0 failed	Direct queries refused; Distributed query returned `ALL_CONNECTION_TRIES_FAILED`	Both replicas matched at 72,274 rows
6	All four data pods failed	Complete SQL outage; 40 attempts and no acknowledgements	Four pods reopened their PVC data
7	Keeper follower kill	Follower UID changed; Keeper-0 remained leader	26/26 attempts acknowledged
8	Keeper leader kill	Keeper-1 became leader	One leader and two followers restored
9	Keeper quorum loss, 90s	Survivor stopped serving; replicated insert timed out	Quorum and queue 0 returned
10	All Keeper members failed	All rejected exec; replicated insert timed out	Quorum reformed
11	500ms network delay	Ping average rose to 517.919ms	Returned to 0.070ms; queue 0
12	30% packet loss	Probe measured 35% loss	Recovery probe measured 0% loss
13	50% packet duplication	Probe reported 8 duplicate packets	Both replicas had 80,556 unique rows
14	1Mbps bandwidth limit	4.5MB transfer took 4.80s	Same transfer took 0.21s
15	Data-replica partition	Peer TCP timed out; replicas diverged; queue reached 12	Automatically matched at 89,357 rows
16	Replica-to-Keeper partition	Target reported `is_readonly=1` and `is_session_expired=1`	Returned writable with two active replicas
17	CPU stress	Two workers used ~44% each; throttling 203 → 455	No restart; queue 0
18	1GiB memory stress	Usage 1.30GB → 2.41GB under a 4GiB limit	Fell to 1.36GB; no OOM
19	100ms filesystem latency	`toda` active; scan 0.00s → 5.78s with transport errors	ext4 and PID `Ssl` returned automatically
20	10% EIO	Read-only probe returned `Input/output error`	Same probe returned exit 0; PID `Ssl`
21	Keeper DNS errors	Target lookup failed; control lookup succeeded	Target DNS resolved again
22	Clock skew −2h	Chaos Mesh stopped PID 1; live skew was not demonstrated	Manual `SIGCONT`; chaos-tool limitation
23	I/O latency plus sibling failure	`toda`, sibling exec failure, SQL refusal, `Critical`	Both replicas matched at 99,019 rows
24	Three-cycle recovery soak	Three target UIDs changed	SQL and checksum checks passed every cycle
25	Existing replica and PVC deletion	PVC UID changed; status retained the old UID; `EXISTS TABLE` returned 0	51,921 rows restored; status advanced to the verified UID; new writes succeeded

Final Integrity Evidence

Finish by checking the ClickHouse resource:

➤ kubectl get clickhouse -n demo clickhouse-chaos
NAME               VERSION   STATUS   AGE
clickhouse-chaos   26.2.6    Ready    105m

Check every database and workload pod:

➤ kubectl get pods -n demo | grep clickhouse-chaos
clickhouse-chaos-chaos-cluster-shard-0-0      1/1   Running   0             39m
clickhouse-chaos-chaos-cluster-shard-0-1      1/1   Running   0             37m
clickhouse-chaos-chaos-cluster-shard-1-0      1/1   Running   0             40m
clickhouse-chaos-chaos-cluster-shard-1-1      1/1   Running   1 (39m ago)   39m
clickhouse-chaos-keeper-0                     1/1   Running   6 (61m ago)   66m
clickhouse-chaos-keeper-1                     1/1   Running   2 (61m ago)   67m
clickhouse-chaos-keeper-2                     1/1   Running   6 (61m ago)   105m
clickhouse-chaos-workload-64d7d5c85f-fqjdp   1/1   Running   0             103m

The Distributed table contained 210,004 rows and every UUID was unique:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id) FROM chaos_v2.events"'
210004  210004

Compare the count, unique-ID count, and checksum on each replica. Matching results within each shard prove that its replicas converged automatically:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
104352  104352  403484691276693588

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
104352  104352  403484691276693588

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
105652  105652  18352531473341875159

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT count(), uniqExact(id), sum(payload) FROM chaos_v2.events_local"'
105652  105652  18352531473341875159

Check replica health separately on all four data pods. The six columns are is_readonly, is_session_expired, queue_size, total_replicas, active_replicas, and absolute_delay:

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT is_readonly, is_session_expired, queue_size, total_replicas, active_replicas, absolute_delay FROM system.replicas WHERE database = '\''chaos_v2'\'' AND table = '\''events_local'\''"'
0  0  0  2  2  0

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-0-1 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT is_readonly, is_session_expired, queue_size, total_replicas, active_replicas, absolute_delay FROM system.replicas WHERE database = '\''chaos_v2'\'' AND table = '\''events_local'\''"'
0  0  0  2  2  0

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-0 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT is_readonly, is_session_expired, queue_size, total_replicas, active_replicas, absolute_delay FROM system.replicas WHERE database = '\''chaos_v2'\'' AND table = '\''events_local'\''"'
0  0  0  2  2  0

➤ kubectl exec -n demo clickhouse-chaos-chaos-cluster-shard-1-1 -c clickhouse -- \
  bash -c 'clickhouse-client --user "$CLICKHOUSE_USER" --password "$CLICKHOUSE_PASSWORD" --query "SELECT is_readonly, is_session_expired, queue_size, total_replicas, active_replicas, absolute_delay FROM system.replicas WHERE database = '\''chaos_v2'\'' AND table = '\''events_local'\''"'
0  0  0  2  2  0

Check each Keeper member separately:

➤ kubectl exec -n demo clickhouse-chaos-keeper-0 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
leader

➤ kubectl exec -n demo clickhouse-chaos-keeper-1 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

➤ kubectl exec -n demo clickhouse-chaos-keeper-2 -c clickhouse-keeper -- bash -c 'exec 3<>/dev/tcp/127.0.0.1/9181; printf "mntr\n" >&3; timeout 3 cat <&3' | awk '$1=="zk_server_state" {print $2}'
follower

Verify that all data PVCs are 4Gi and all Keeper PVCs are 1Gi:

➤ kubectl get pvc -n demo | grep clickhouse-chaos
data-clickhouse-chaos-chaos-cluster-shard-0-0   Bound   pvc-9773c0e0-8bd6-4a67-b445-444255b61074   4Gi   RWO   local-path   <unset>   105m
data-clickhouse-chaos-chaos-cluster-shard-0-1   Bound   pvc-11b51f42-bd68-483e-b537-e3bf349c40b3   4Gi   RWO   local-path   <unset>   37m
data-clickhouse-chaos-chaos-cluster-shard-1-0   Bound   pvc-eecf7db8-b9b5-4888-b1aa-71e70ea65119   4Gi   RWO   local-path   <unset>   105m
data-clickhouse-chaos-chaos-cluster-shard-1-1   Bound   pvc-35ef4112-0c9d-42b1-973a-f26389b04864   4Gi   RWO   local-path   <unset>   105m
data-clickhouse-chaos-keeper-0                  Bound   pvc-531f098d-5196-490d-b6ba-b3584755b06c   1Gi   RWO   local-path   <unset>   105m
data-clickhouse-chaos-keeper-1                  Bound   pvc-41c5eecc-1f51-477d-aa7f-22e2e1c88ba9   1Gi   RWO   local-path   <unset>   105m
data-clickhouse-chaos-keeper-2                  Bound   pvc-e893bff9-8ba5-4da4-92f7-b0b125e4777f   1Gi   RWO   local-path   <unset>   105m

Finally, prove that no experiment remains active:

➤ kubectl get podchaos,networkchaos,stresschaos,iochaos,dnschaos,timechaos -n demo
No resources found in demo namespace.

The final workload counters were 2,227 attempted batches, 2,055 acknowledged batches, and 172 failed or ambiguous attempts. The database contained 210,004 unique rows. The 4,504 rows above 2,055 × 100 came from inserts for which ClickHouse accepted data but the client did not receive a success response before its timeout. They are not duplicate IDs.

Error Interpretation

Client timeout or connection failure: the selected shard, all data pods, Keeper, network, or storage was temporarily unavailable. Failed attempts are expected during those tests.
Critical ClickHouse phase: at least part of the desired cluster was not healthy. It does not always mean every query is unavailable.
ClickHouse stayed Ready during Keeper loss: the health check could still connect to ClickHouse, but Keeper-dependent operations were degraded. Check Keeper directly rather than relying on one status field.
Temporary replica count mismatch: a part accepted around Keeper recovery was still propagating. It became a problem only if consecutive checks failed to converge within the recovery timeout.
REPLICA_ALREADY_EXISTS after PVC loss: the new disk had no local table, but Keeper still remembered the old replica registration. This was the expected intermediate condition. The recovery controller removed the stale registration before replaying the sibling’s table definition.
EXISTS TABLE returned 0: the replacement ClickHouse process was reachable, but its new PVC contained no local schema. This proved the test caused real disk loss rather than an ordinary pod restart.
Input/output error and CANNOT_STATVFS: IOChaos deliberately made filesystem calls return EIO. These errors disappeared after the fault.
PID state Tsl: the TimeChaos run left ClickHouse stopped even after Chaos Mesh reported recovery. SIGCONT resumed the process without deleting data or recreating the pod. This indicates an incomplete chaos-tool cleanup, not data corruption.

Key Findings

Replica and Keeper redundancy protected acknowledged data across every tested recoverable failure.
ClickHouse Ready is insufficient for Keeper-specific faults. An authenticated database query, replica state, and Keeper mntr must also be checked.
Unique row IDs are essential because a timed-out Distributed insert can have an ambiguous partial result.
Recovery verification needs consecutive matching replica checks, not one instantaneous queue sample.
Chaos Mesh 2.8.4 handled PodChaos, NetworkChaos, StressChaos, DNSChaos, and both I/O cases cleanly. TimeChaos stopped the target and required manual SIGCONT, so this run did not validate a functioning live clock skew.
Memory pressure rose to about 2.42GiB under a 4GiB limit without an OOM, then fell toward baseline after cleanup.
Losing both a replica pod and its PVC requires schema recovery before normal ClickHouse replication can resume. The recovery-enabled KubeDB operator removed stale Keeper registrations, restored the schema from the same-shard sibling, and allowed ReplicatedMergeTree to fetch the data automatically.

Conclusion

The results show that the tested ClickHouse topology protected acknowledged data across pod, process, Keeper, network, CPU, memory, storage, DNS, combined failures, and permanent loss of one replica’s PVC. Expected downtime occurred when an entire shard or the whole data plane was unavailable; that is correct behavior for this topology, not a failed recovery mechanism.

A ClickHouse status field alone is not a complete health check. Recovery verification requires an authenticated read and write, shard-local count and checksum equality, system.replicas state, Keeper quorum, process state, and clean storage mounts.

Experiment 22 separates database resilience from chaos-tool behavior. ClickHouse data recovered, but Chaos Mesh 2.8.4 stopped the affected process and did not resume it automatically. Because a live two-hour skew was not observed, that experiment is reported as a chaos-tool limitation, not a pass.

Optional Cleanup

The tested cluster remained running after the final evidence was captured. For a cluster created only for this walkthrough, first confirm that no chaos experiment remains active:

➤ kubectl get podchaos,networkchaos,stresschaos,iochaos,dnschaos,timechaos -n demo
No resources found in demo namespace.

Then remove the workload resources and the ClickHouse resource:

➤ kubectl delete deployment -n demo clickhouse-chaos-workload --ignore-not-found

➤ kubectl delete configmap -n demo clickhouse-chaos-workload --ignore-not-found

➤ kubectl delete clickhouse -n demo clickhouse-chaos --ignore-not-found

The test manifest uses deletionPolicy: WipeOut, so KubeDB also removes the managed pods, generated authentication Secret, and PVCs. Do not delete a PVC manually while its pod is terminating. Verify cleanup with:

➤ kubectl get clickhouse,petset,pods,pvc,secrets -n demo -o name | grep clickhouse-chaos

The final command should print nothing. These cleanup commands are intentionally shown without captured deletion output because they were not run against the cluster used to produce this article.

KubeDB

KubeStash New

Stash

KubeVault

Voyager

ConfigSyncer

Guard

Application Modernization

Managed Cloud

Managed Kubernetes

Managed Databases

Platform Engineering

Product Engineering

Site Reliability Engineering

Observability & DevSecOps

Monolith to Microservices

GitOps Consulting

CI/CD & Dev Experience

DevOps Toolchain

Argo CD Consulting

Managed AWS

Managed Azure

Managed GCP

Kubernetes Consulting Services

AWS EKS Consulting

Azure AKS Consulting

Google GKE Consulting

Red Hat OpenShift Consulting

Rancher by SUSE Consulting

VMware Tanzu Consulting

Managed Databases

Platform Engineering Services

Progressive Delivery

CI/CD & Dev Experience

Bare Metal Provisioning Consulting

Cloud Native Product Development

Monolith to Microservices

Extending Kubernetes? Custom Resources & Controllers

SRE Consulting

Service Mesh Consulting

Cloud Native Networking

Istio Consulting

Terraform Consulting

Backup & Disaster Recovery

DevSecOps Consulting

Observability Adoption

Grafana Consulting

Prometheus Consulting

Blog

Docs

Webinars

Learn

Videos

Chaos Testing KubeDB ClickHouse with Chaos Mesh

Chaos Testing KubeDB ClickHouse with Chaos Mesh

Prerequisites and Cluster Setup

Verify KubeDB and Chaos Mesh Installation

Test Scope

Test Procedure

Create a ClickHouse Cluster

Create setup/clickhouse-chaos.yaml

Test Environment

Chaos Testing

Continuous ClickHouse Write Workload

Create setup/clickhouse-workload.yaml

Mandatory Recovery Gate

Running Each Chaos Experiment

Pod and Keeper Chaos

Chaos#1: Kill One ClickHouse Replica

Create tests/01-pod-kill.yaml

Resume the workload

Demonstrate impact and recovery

Pause the workload

Chaos#2: Hold One Replica Failed

Create tests/02-pod-failure.yaml

Resume the workload

Pause the workload

Chaos#3: Kill Only the ClickHouse Container

Create tests/03-container-kill.yaml

Resume the workload

Create `setup/clickhouse-chaos.yaml`

Create `setup/clickhouse-workload.yaml`

Create `tests/01-pod-kill.yaml`

Create `tests/02-pod-failure.yaml`

Create `tests/03-container-kill.yaml`

Create `tests/04-a-pod-kill.yaml`

Create `tests/04-b-pod-kill.yaml`

Create `tests/04-c-pod-kill.yaml`

Create `tests/05-full-shard-outage.yaml`

Create `tests/06-data-plane-outage.yaml`

Create `tests/07-keeper-follower-kill.yaml`

Create `tests/08-keeper-leader-kill.yaml`

Create `tests/09-keeper-quorum-loss.yaml`

Create `tests/10-full-keeper-outage.yaml`

Create `tests/11-network-delay.yaml`

Create `tests/12-network-loss.yaml`

Create `tests/13-network-duplicate.yaml`

Create `tests/14-bandwidth.yaml`

Create `tests/15-data-partition.yaml`

Create `tests/16-keeper-partition.yaml`
